11
420E/420E IT Specifications
Engine
Engine Model
(Standard) Cat ® C4.4
ACERT ® DIT
Gross Power
– SAE J1995 75 kW 101 hp
Gross Power
– ISO 14396 75 kW 101 hp
Net Power
– SAE J1349 69 kW 93 hp
Net Power
– ISO 9249 70 kW 94 hp
Net Power
– EEC 80/1269 70 kW 94 hp
Net Peak Power @
1,800 rpm – SAE
J1349 71 kW 95 hp
Net Peak Power
@ 1,800 rpm
– ISO 9249 72 kW 97 hp
Net Peak Power
@ 1,800 rpm
– EEC 80/1269 72 kW 97 hp
Bore 105 mm 4.13 in
Stroke 127 mm 5 in
Displacement 4.4 L 268 in 3
Net Torque Rise
@ 1,400 rpm
– Standard 36%
Net Peak Torque
@ 1,400 rpm
– Standard
– SAE J1349 408 N·m 301 lb ft
Engine meets all U.S. EPA Tier 3/
EU Stage IIIa emissions requirements.
The net power ratings apply at 2,200 rpm
when tested under the specified conditions
for the specified standard.
Net power advertised is the power available
at the flywheel when the engine is equipped
with fan, air cleaner, muffler and alternator.
Based on standard air conditions of
25° C (77° F) and 99 kPa (29.32 in)
in dry barometer.
Used 35° API gravity fuel having an LHV
of 42 780 kJ/kg (18,390 BTU/lb) when used
at 30° C (89° F) (reference a fuel density
of 838.9 g/L [7.001 lb/gal]).
No derating required up to 3000 m
(9,843 ft).
Net torque rise meets SAE J1349.
Net peak power ratings apply at conditions
specified above.
•
•
•
•
•
•
•
•
Weights
Operating Weight
– Nominal 6895 kg 15,201 lb
Operating Weight
– Maximum 11 000 kg 24,251 lb
Cab, ROPS/FOPS 260 kg 573 lb
Auto-Shift
Transmission 27 kg 60 lb
Ride Control 25 kg 55 lb
Air Conditioning 39 kg 86 lb
Four Wheel Drive 155 kg 342 lb
Loader, IT w/QC 365 kg 805 lb
Extendible Stick
(no weights) 299 kg 659 lb
Counterweights
(Option 1) 116 kg 255 lb
Counterweights
(Option 2) 231 kg 510 lb
Counterweights
(Option 3) 488 kg 1,075 lb
Total gross machine weight not to exceed
11 000 kg (24,251 lb).
•
Backhoe
Dig Depth
– Standard 4360 mm 14 ft 4 in
E-Stick Retracted 4402 mm 14 ft 5 in
E-Stick Extended 5456 mm 17 ft 11 in
Reach from Swing
Pivot – Standard 5618 mm 18 ft 5 in
E-Stick Retracted 5657 mm 18 ft 7 in
E-Stick Extended 6666 mm 21 ft 10 in
Bucket Rotation 205 Degrees
Bucket Dig Force
– Standard 61.7 kN 13,875 lb
E-Stick Retracted 60.9 kN 13,863 lb
E-Stick Extended 60.9 kN 13,863 lb
Stick Dig Force
– Standard 43 kN 9,662 lb
E-Stick Retracted 42.8 kN 9,616 lb
E-Stick Extended 31.2 kN 7,023 lb
Stick Lift @
2440 mm (8 ft)
– Standard 2601 kg 5,722 lb
E-Stick Retracted 2408 kg 5,298 lb
E-Stick Extended 1620 kg 3,564 lb
Loading Height
– Standard 3636 mm 11 ft 11 in
E-Stick Retracted 3577 mm 11 ft 9 in
E-Stick Extended 4145 mm 13 ft 7 in
Loading Reach
– Standard 1768 mm 5 ft 10 in
E-Stick Retracted 1868 mm 6 ft 1 in
E-Stick Extended 2771 mm 9 ft 1 in
