ALTV248ULseries - 9 -
White
Lead
XFMR*
Black
Lead
115VAC input,
60 Hz.
XFMR*
IN
PU
T
N
P
S
IN
PU
T
N
P
S
Green
Lead
(Ground)
Connected
to Door
non-power limited
non-power limited
non-power limited
MAIN FUSE
MA IN FU SE
Illuminated Power Disconnect
Circuit Breaker with manual reset
Class 1 outputs
24VAC or 28VAC fused ( Follow same
procedure using terminals 2P & N thru 4P & N
outputs 2 thru 4).
Fig. 9
ALTV248600UL
Fig. 9a
