ALTV248UL Series

CCTV Power Supplies
Installation Guide

Models Include:

ALTV248UL

ALTV248ULCB

- 24VAC @ 3.5 amp (85VA)

- 24VAC @ 3.5 amp (85VA)

or 28VAC @ 3 amp (85VA).

or 28VAC @ 3 amp (85VA).

- Eight (8) Fuse Protected Outputs.

- Eight (8) PTC Protected Outputs.

ALTV248175UL

ALTV248175ULCB

- 24VAC @ 7 amp (175VA)

- 24VAC @ 7 amp (175VA)

or 28VAC @ 6.25 amp (175VA).

or 28VAC @ 6.25 amp (175VA).

- Eight (8) Fuse Protected Outputs.

- Eight (8) PTC Protected Outputs.

ALTV248300UL

ALTV248300ULCB

- 24VAC @ 12.5 amp (300VA)

- 24VAC @ 12.5 amp (300VA)

or 28VAC @ 10 amp (280VA).

or 28VAC @ 10 amp (280VA).

- Eight (8) Fuse Protected Outputs.

- Eight (8) PTC Protected Outputs.

ALTV248300ULM

ALTV248300ULCBM

- 24VAC @ 12.5 amp (300VA)

- 24VAC @ 12.5 amp (300VA)

or 28VAC @ 10 amp (280VA).

or 28VAC @ 10 amp (280VA).

- Eight (8) Fuse Protected Outputs.

- Eight (8) PTC Protected Outputs.

ALTV248600UL

ALTV248600ULCB

- 24VAC @ 25 amp (600VA)

- 24VAC @ 25 amp (600VA)

or 28VAC @ 20 amp (560VA).

or 28VAC @ 20 amp (560VA)

- Eight (8) Fuse Protected Outputs.

- Eight (8) PTC Protected Outputs.

Rev. 040506
