ALTV248ULseries - 5 -
Fig. 1
ALTV248UL
XFMR
White
Lead
Black
Lead
Black
Lead
non-power
limited
non-power
limited
115VAC Input,
60 Hz.
Green
Lead
(Ground)
ON
OFF
MAIN FUSE
COMMON POWER OUTPUTS
FUSED POWER OUTPUTS
N P S
Primary
In-line
Fuse
Class 1 Outputs
24VAC or 28VAC
output 1 (Follow
same procedure using
terminals 2P & N
through 8P & N
outputs 2 through 8)
ON
OF
F
Back Panel of Enclosure
Back Panel of Enclosure
Fig. 2
ALTV248ULCB
N
COMMON POWER OUTPUTS
P
FUSED POWER OUTPUTS
D1
INPUT
N P S
R1
LED
MAIN
FUSE F1 F2 F3 F4 F5 F6 F7 F8
ON
OF
F
XFMR
White
Lead
Black
Lead
Black
Lead
non-power
limited
non-power
limited
115VAC Input,
60 Hz.
Green
Lead
(Ground)
Primary
In-line
Fuse
24VAC configuration Class 2 Not Wet/Class 3 Wet
28VAC configuration Class 1
24VAC or 28VAC
output 1
(Follow same
procedure using
terminals 2P & N
through 8P & N
outputs 2 through 8) ON
OF
F
Fig. 1a
Fig. 2a
