ALTV248ULseries - 7 -
White Lead
N
COMMON POWER OUTPUTS
P
FUSED POWER OUTPUTS
D1
INPUT
N P S
R1 LED
non-power
limited
XFMR*
115VAC input
60 Hz
Green
Lead
(ground)
M
A IN
F
U
SE
Illuminated Power Disconnect
Circuit Breaker with manual reset
Class 1 Outputs
24VAC or 28VAC
output 1 (Follow
same procedure using
terminals 2P & N
through 8P & N
outputs 2 through 8)
Fig. 5
ALTV248300UL
White Lead
non-power
limited
XFMR*
115VAC input
60 Hz
Green
Lead
(ground)
Illuminated Power Disconnect
Circuit Breaker with manual reset
Class 2 Not Wet/Class 3 Wet
24VAC or 28VAC
output 1
(Follow same
procedure using
terminals 2P & N
through 8P & N
outputs 2 through 8)
Fig. 6
ALTV248300ULCB
Fig. 5a
Fig. 6a
