Vibration resistance
mechanical vibration with 1 g in the frequency
range 5 … 200 Hz
6)
Electromechanical data
Cable entry
-
Double chamber housing
l
1x cable entry M20x1.5 (cable-ø 5 … 9 mm),
1x blind stopper M20x1.5; plug M12x1 for
VEGADIS 61
or:
l
1x closing cap ½ NPT, 1x blind stopper
½ NPT, plug M12x1 for VEGADIS 61
or:
l
1x plug M12x1, 1x blind stopper M20x1.5,
plug M12x1 for VEGADIS 61
Spring-loaded terminals
for wire cross-section up to 2.5 mm²
Transducer cable
7)
-
length
5 … 300 m (16.4 … 984.3 ft)
-
Diameter
9.5 … 9.9 mm
Indicating and adjustment module
Power supply and data transmission
through sensor via gold-plated sliding contacts
(I²C bus)
Display
LC display in dot matrix
Adjustment elements
4 keys
Protection
-
unassembled
IP 20
-
mounted into the sensor without
cover
IP 40
Materials
-
Housing
ABS
-
Inspection window
Polyester foil
Voltage supply
Supply voltage
-
Non-Ex and Exd instrument
20 … 72 V DC, 20 … 253 V AC, 50/60 Hz
Power consumption
max. 4 VA; 2.1 W
6)
Tested according to the regulations of German Lloyd, GL directive 1
7)
With separate version C and D.
