10 Supplement
10.1 Technical data
General data
Materials, wetted parts
- Flange PP or Alu
- Swivelling holder, flange galvanized steel
- Transducer UP
- Transducer diaphragm Alu, PFTA-coated
Materials, non-wetted parts
- Housing Alu die-casting powder-coated
- Seal ring between housing and
housing cover
silicone
- Inspection window in housing cover
for PLICSCOM
Polycarbonate (UL-746-C listed)
- Ground terminal 316Ti/316L
- transducer cable with separate ver-
sion C and D
silicone (1.1083)
Weight
3)
- compact with flange (version A) 7.3 … 11.3 kg (16.1 … 24.9 lbs)
- compact with swivelling holder
(version B)
8.7 … 10.3 kg (19.1 … 22.7 lbs)
- separate with swivelling holder
(version C)
9.3 … 11.1 kg (20.5 … 25.5 lbs)
- separate with threaded fitting
(version D)
6.5 … 7.5 kg (14.3 … 16.5 lbs)
Output variable
Output
- Signal digital output signal, Foundation Fieldbus pro-
tocol
- Physical layer according to IEC 61158-2
Channel Numbers
- Channel 1 Primary value
- Channel 2 Secondary Value 1
3) Depending on size and process fitting material.
