Important: See Safety Information in General Information Section (J300P-GI)
J300P-5
TUBE YOKES
9 Important: See Safety Information in General Information Section (J300P-GI)
• Part is discontinued  Part is available until supply is exhausted © Not sold separately
For Use With F H Used in Tube Yoke Tube Yoke
Tube Diameter & Wall Butt Diameter C-line to Point of Weld & Yoke Assembly Part Number
1760 SERIES E=7.000 (HR STYLE=7.094) D=1.938 USE KIT NO. 5-407X, 5-677X
4.095 X.180 W 3.743 3.031 — 6.3-28-17
1810 SERIES E=7.547 (HR STYLE=7.643) D=1.938 USE KIT NO. 5-281X, 5-676X
4.500 X.134 W 4.243 3.375 6.5-27-9 6.5-28-117
4.500 X.259 W 4.003 3.375 — 6.5-28-127
1880 SERIES E=8.094 D=2.188 USE KIT 5-308X
4.500 X.259 W 4.003 4.000 — 8-28-147
1950 SERIES E=10.094 D=3.062 USE KIT 5-192X
6.000 X.500 S 5.125 6.531 — 9-26-18X•
5C SERIES P=4.531 S=1.685 KEYWAY-.563 USE KIT 050776010,050370000
2.500 X.159 W 2.186 2.224 — 5C-28-27•
.375-24 Threaded Holes
6C SERIES P=5.531 S=1.689 KEYWAY-.563 USE KIT 050138010,050273000
2.756 X.159 W 2.448 1.870 — 6C-28-27•
.375-24 Threaded Holes
