Important: See Safety Information in General Information Section (J300P-GI)

J300P-5

HOW TO USE THIS CATALOG

Important: See Safety Information in General Information Section (J300P-GI)

This publication contains data on Spicer center yokes and ball stud tube yokes for double cardan

driveshafts and Spicer tube yokes for single cardan driveshafts.

HOW TO IDENTIFY A CENTER YOKE USING THIS CATALOG

To identify any center yoke, three pieces of information are required:
1. Determine the Series
2. Determine the dimension between center of U-Joint to center of U-Joint
3. Determine the type of part (circular or rectangular)
Example: To find a 1310 Series rectangular type, with a center to center dimension of 2.75, see the

following example:
1. Find the 1310 Series heading
2. Find the Center to Center dimension of 2.750
3. Find a type 1 (circular is type 2, rectangular is type 1)

Order Spicer Center Yoke Part Number 2-26-177

Be sure to read any notes that are provided.
Series and all pertinent series dimensions appear as shown in the sample below:

1310 SERIES

E-3.469 D-1.062

USE KIT 5-153X, 5-785X, 5-810X, 5-786X

2.688

3.875

2-26-477

2.688

3.875

2-26-497

2.688

3.875

2-26-507

Lube hole thru web

2.750

3.875

2-26-177

3.000

3.875

2-26-257

HOW TO IDENTIFY A TUBE YOKE USING THIS CATALOG

To identify any tube yoke, three pieces of information are required:
1. Determine Series
2. Determine the size and wall thickness of the tube it fits
3. Determine the dimension from center of joint to weld point
Example: To find a 1330 Series with a 2.000 center to weld dimension, that fits a 2.750 OD tube with a

.065 wall thickness, see the following example:
1. Find the 1330 Series heading
2. Find the 2.750 Tubing Diameter and .065 wall thickness (2.750 x .065 - S=Seamless, W=Welded)
3. Find the 2.000 Center to Weld dimension

Be sure to read any notes that are provided. Order Spicer Tube Yoke Part Number 5004393

Series and all pertinent series dimensions appear as shown in the sample below:

1330 SERIES

E-3.875 D-1.062

USE KIT 5-213X, 5-790X, 5-812X, 5-791X

2.000 X.120W

1.766

2.120

2-28-2777

2.500 X.083W

2.344

1.719

2-28-1707

2.500 X.083W

2.344

2.537

2-28-3347•

2.750 X.065S

2.625

2.000

5004393

2.750 X.065W

2.625

2.540

5002395

2.750 X.083S

2.594

2.030

2-28-3937

Center to Center

Swing Diameter

Type

Center Yoke

For Use With

Used in Tube Yoke

Tube Yoke

Tube Diameter & Wall

Butt Diameter C-line to Point of Weld & Yoke Assembly

Part Number
