J300P-5
ALUMINUM TUBE YOKES
11 Important: See Safety Information in General Information Section (J300P-GI)
• Part is discontinued  Part is available until supply is exhausted © Not sold separately
For Use With F H Used in Tube Yoke Tube Yoke
Tube Diameter & Wall Butt Diameter C-line to Point of Weld & Yoke Assembly Part Number
1350 SERIES E=3.875 D=1.188 USE KIT 5-3615X
3.500 X.120 S 3.280 1.837 — 3-28-977
3.500 X.165 S 3.188 1.837 — 3-28-1197
4.000 X.083 S 3.855 2.125 — 3-28-1297
4.000 X.083 S 3.855 2.406 — 3-28-1307
4.160 X.086 S 3.998 2.130 — 3-28-1617
4.160 X.086 S 3.998 2.410 — 3-28-1437•
4.500 X.065 S 4.388 4.000 — 3-28-10274
4.500 X.065 S 4.388 4.000 — 5010274
5010274 will be replaced by 2-28-10247 when supply is exhausted
4.520 X.075 S 4.388 2.130 — 3-28-1407
4.575 X.134 S 4.325 3.173 — 5006297•
4.575 X.134 W 4.325 3.173 — 3-28-07154
w/vent hole thru web
4.575 X.134 W 4.325 3.173 — 5007154
5007154 will be replaced by 2-28-07154 when supply is exhausted; w/vent hole thru web
5.000 X.065 S 4.888 1.840 — 3-28-01701©
5.000 X.065 S 4.888 1.840 — 5001701
5001701 will be replaced by 2-28-01701 when supply is exhausted
5.000 X.065 S 4.888 1.844 — 3-28-1347
5.000 X.065 S 4.888 4.110 — 3-28-1447
5.086 X.103 S 4.888 3.173 — 5012681
5012681 will be replaced by 2-28-12681 when supply is exhausted
5.086 X.106 S 4.888 3.173 — 3-28-1287©
5.086 X.106 S 4.888 3.173 — 3-28-12681
5.090 X.107 S 4.876 3.173 — 3-28-06301
w/vent hole thru web
5.090 X.107 S 4.888 3.173 — 3-28-07058
5.090 X.107 S 4.876 3.173 — 5006301
5006301 will be replaced by 2-28-06301 when supply is exhausted; w/vent hole thru web
5.090 X.107 S 4.888 3.173 — 5007058
5007058 will be replaced by 2-28-07058 when supply is exhausted
1410 SERIES E=4.438 D=1.188 USE KIT 5-3616X
4.000 X.083 S 3.853 2.290 — 3-28-1607•
4.000 X.083 W 3.855 2.130 — 3-28-03535
4.000 X.083 W 3.855 2.130 — 3-28-03536
4.000 X.083 W 3.855 2.130 — 5003535
5003535 will be replaced by 2-28-03535 when supply is exhausted; Use plug no. 232639 in vent hole
4.000 X.083 W 3.855 2.130 — 5003536
5003536 will be replaced by 2-28-03536 when supply is exhausted;
4.000 X.103 S 3.812 2.125 — 3-28-1537•
4.157 X.087 S 3.998 2.290 — 3-28-1757
4.500 X.098 S 4.325 2.125 — 3-28-1387•
4.510 X.063 S 4.384 2.290 — 3-28-1547
Use plug no. 232639 in vent hole
4.510 X.063 S 4.384 2.290 — 3-28-1597•
5.000 X.063 S 4.888 2.281 — 3-28-1647
5.000 X.065 S 4.888 4.109 — 3-28-1657
