HOW TO USE THIS CATALOG

Footnotes for parts and assemblies that are discontinued, will be discontinued upon depletion of

stock, or not sold separately, are indicated by a symbol next to the part number. Match the symbol

to the appropriate status at the bottom of the page. All other footnotes are located immediately

below the yoke dimensional data.

IMPORTANT NOTICE: The data listed herein is correct to the best of our knowledge and belief;

having been compiled from reliable and official sources of information. However, WE CANNOT

ASSUME ANY RESPONSIBILITY for possible error.

HOW TO IDENTIFY A BALL STUD TUBE YOKE USING THIS CATALOG

To identify any tube yoke, the following information is required:
1. Determine the Series
2. Determine the size and wall thickness of the tube it fits
3. Determine the dimension from center of joint to weld point
4. Determine the center of the joint to the end of the ball stud dimension
5. Determine the diameter of the ball stud
6. Determine the length of the ball stud
7. Determine the configuration and dimensions of the slinger or seal (if the part has a slinger or seal)
Example: To find a 1310 Series ball stud tube yoke with a 1.438 center to weld dimension, that fits a

2.000 OD tube with a .120 wall thickness and a .500 diameter ball stud, see the following example:
1. Find the 1310 Series heading
2. Find the 2.000 Tubing Diameter and .120 wall thickness (2.000 x .120W)
3. Find the 1.440 Center to Weld dimension
4. Find the 1.641 Center to End of Ball Stud dimension
5. Find the .594 Ball Stud Length

6. Refer to the slinger and seal illustrations on page 13 to determine which seal/slinger configuration

you have.

If you have a seal, order Spicer ball stud tube yoke assembly part number 2-28-2867X

If you have a slinger, order Spicer ball stud tube yoke assembly part number 2-28-2947X

Be sure to read any notes that are provided.

Series and all pertinent series dimensions appear as shown in the sample below:

1310 SERIES

E-3.469 D-1.062

USE KIT 5-153X, 5-785X, 5-810X, 5-786X

1.250 X.120 W

1.016

1.500

1.641

.594

.500

231864

2-28-2997X

1.750 X.095 W

1.562

1.440

1.641

.594

.500

2-86-418

2-28-2827X

1.750 X.095 W

1.562

1.440

1.641

.594

.500

231864

2-28-2937X

2.000 X.120 W

1.766

1.440

1.641

.594

.500

2-86-418

2-28-2867X

2.000 X.120 W

1.766

1.440

1.641

.594

.500

231864

2-28-2947X

2.500 X.065 W

2.375

1.440

1.641

.594

.500

2-86-418

2-28-3087X

For Use With

Ball Stud

Tube

Butt

Centerline Centerline

Slinger/Seal

Tube Yoke

Diameter

Diameter to Point to End of

Length Diameter

Assembly

& Wall Thickness

of Weld

Ball Stud

Part Number
