Socket yoke assembly dimensions, J300p-5, Style 1 style 2 style 1 – Spicer Driveline Components Catalog - Center Yokes, Tube Yokes and Ball, Stud Tube Yokes User Manual
Page 13
Important: See Safety Information in General Information Section (J300P-GI)
J300P-5
13
Important: See Safety Information in General Information Section (J300P-GI)
Bolt Holes Dimensions
Fits
C/L
Diameter to End
Ball Stud
A
B
C
D
E
Size
Flanged Socket
Bolt Circle
Yoke Assembly Series Style Diameter
Style 1
Style 2
Style 1
Bolt Holes Dimensions
C/L
to End
Ball Stud
A
B
C
E
Size
Flanged Socket
Bolt Circle
Yoke Assembly Series Style Diameter
211489X●
1210
1
3.500
2.468
2.468
0.484
2.000
1.625
0.500
211543X■◊
1310
1
3.500
2.484
2.484
0.484
2.000
1.625
0.500
211229X■► 1310
1
3.500
2.484
2.484
0.484
2.000
1.625
0.500
212130X■
1310
1
*
3.750
2.712
2.712
0.401
2.750M
1.500
0.522
211198X●
1310
1
4.000
2.937
2.937
0.453
3.125
1.625
0.500
211452X●
1310
1
4.250
3.000
3.000
0.453
3.125
1.625
0.500
211545X■
1310
1
4.250
3.000
3.000
0.453
3.125
1.625
0.500
212040X■
1310
1
4.250
3.000
3.000
0.488
3.126
1.620
0.500
211631X■
1330
1
4.250
3.000
3.000 M12X1.75th’d 2.000
1.625
0.500
211889X●
1330
2
4.000
2.953
2.656
0.453
3.125
1.875
0.500
211606X
1330
2
4.000
2.953
2.656
0.453
3.125
1.812
0.500
211520X●
1330
2
4.000
2.953
2.656
0.453
3.125
1.875
0.625
211868X●
1330
2
4.250
3.000
3.000
0.453
3.125
1.812
0.500
211913X■
1330
1
4.250
3.000
3.000
0.462
3.125
1.625
0.500
212024X■
1350
1
4.250
3.000
3.000 M12X1.75th’d 2.000
1.625
0.500
212025X■
1350
1
4.250
3.000
3.000 M12X1.75th’d 2.680
1.625
0.500
** 5009419■
1350
1
4.250
3.000
3.000
0.459
3.125
1.620
0.500
211342X
1210
3
2.437
1.500
2.343
.250-28th’d
1.531
0.500
211519X
1210
—
2.437
1.500
2.343
.250-28th’d
1.640
has .500 stud
211355X
1310
3
3.218
1.500
2.343
.312-24th’d
1.531
0.500
211544X■◊
1310
3
3.218
1.500
2.343
.312-24th’d
1.656
0.500
211179X●
1330
3
3.625
1.500
2.875
.312-24th’d
1.562
0.500
210841X
1330
3
3.625
1.500
2.875
.312-24th’d
1.562
0.625
211996X■◊
1330
3
3.625
1.500
2.875
.312-24th’d
1.690
0.500
212019X■
1350
3
3.625
1.625
2.750
.312-24th’d
1.757
0.500
SOCKET YOKE ASSEMBLY DIMENSIONS
● Flush Zerk (#230977)
► Socket OD 1.394
■ Non-Greasable
◊ Socket OD 1.625
*Male Pilot
**2-12-229 sprint not included
