Page 7
Important: See Safety Information in General Information Section (J300P-GI)
J300P-5
TUBE YOKES
7
Important: See Safety Information in General Information Section (J300P-GI)
•
Part is discontinued Part is available until supply is exhausted
©
Not sold separately
For Use With
F
H
Used in Tube Yoke
Tube Yoke
Tube Diameter & Wall
Butt Diameter C-line to Point of Weld & Yoke Assembly
Part Number
1330 SERIES
E=3.875 (UB,BS STYLE E=3.625) D=1.062
USE KIT 5-213X, 5-1330X
2.000 X.120 W
1.771
2.125
—
2-28-2777
2.500 X.083 W
2.345
1.719
—
2-28-1707
2.500 X.083 W
2.344
2.537
—
2-28-3347•
2.750 X.065 S
2.631
2.000
—
5004393
2.750 X.065 W
2.625
2.540
—
5002395•
2.750 X.083 S
2.595
2.031
—
2-28-3937
2.750 X.083 W
2.591
2.539
—
2-28-4017
3.000 X.065 W
2.881
1.719
—
2-28-1177
3.000 X.083 W
2.845
1.719
—
2-28-1697
3.000 X.083 W
2.844
2.165
—
2-28-4037©
3.000 X.083 W
2.844
2.240
—
2-28-06030
3.000 X.083 W
2.844
2.240
—
5006030
5006030 will be replaced by 2-28-06030 when supply is exhausted
3.500 X.065 W
3.381
1.812
—
2-28-1977
3.500 X.065 W
3.370
2.413
—
5002389•
3.500 X.083 W
2.345
1.812
—
2-28-1717
4.000 X.065 W
3.881
2.220
—
5012027
5012027 will be replaced by 2-28-12027 when supply is exhausted
4.000 X.065 W
3.881
1.688
—
2-28-3787
4.000 X.065 W
3.881
2.220
—
2-28-12027
4.000 X.065 W
3.881
2.220
—
3-28-06456
4.000 X.065 W
3.881
2.220
—
5006456
5006456 will be replaced by 2-28-06456 when supply is exhausted
4.000 X.083 W
3.844
1.688
—
2-28-1967
1350 SERIES
E=3.875 (UB,BS STYLE E=3.625) D=1.188
USE KIT 5-178X, 5-1350X
2.000 X.120 W
1.771
2.000
—
3-26-117
2.000 X.120 W
1.771
2.125
—
3-28-777
2.500 X.083 W
2.345
1.938
3-27-1
3-28-47
2.750 X.065 W
2.631
2.031
—
3-28-1107§
3.000 X.065 W
2.881
2.030
—
3-28-137
3.000 X.083 W
2.845
2.000
3-27-2
3-28-57
3.000 X.083 W
2.844
2.031
—
3-28-1157
3-28-1157 was replaced by 3-28-57
3.000 X.095 W
2.821
2.000
—
3-28-157
3.000 X.134 W
2.734
1.970
—
3-28-1137•
3.500 X.065 W
3.381
1.812
3-27-5
3-28-257
3.500 X.083 W
3.345
1.840
—
3-28-427
4.000 X.065 W
3.884
1.690
—
3-28-1667
4.000 X.083 W
3.844
1.688
—
3-28-417
1410 SERIES
E=4.438 (UB,BS STYLE E=4.188) D=1.188
USE KIT 5-160X, 5-1410X
2.500 X.095 W
2.321
2.000
—
3-28-327
2.500 X.156 S
2.217
2.000
—
3-26-437
2.750 X.083 W
2.595
1.625
—
3-28-987
3.000 X.083 W
2.845
1.625
—
3-28-447
3.000 X.083 W
2.845
2.125
3-27-3
3-28-97
3.000 X.095 W
2.821
2.125
3-27-6
3-28-267
3.000 X.134 W
2.742
1.624
—
3-28-997§
3.000 X.250 W
2.500
1.625
—
3-28-1117•
3.500 X.065 W
3.381
2.125
3-27-8
3-28-367
3.500 X.083 W
3.345
2.125
3-27-4
3-28-557
3.500 X.095 W
3.321
2.125
—
3-28-857•
4.000 X.065 W
3.884
1.880
—
3-28-1267
