Lube Capacity (Approx.**) 23 pints 11 liters
Flanged Hex Nut 1-3/4" - 12 8 700 - 900 950 - 1,220
Differential Bearing Cap Bolts 9/16" - 18 8 115 - 135 155 - 183
Differential Case Nuts 1/2" - 13 8 75 - 90 100 - 120
Differential Case Oil Scoop Bolts 1/4" - 20 8 7 - 9 9 - 12
Axle Flange to Wheel Hub Nuts 9/16" - 18 5 95 - 115 129 -155
Pinion Bearing Cage Bolts 9/16" - 12 8 160 - 180 217 - 244
Pinion Bearing Preload*
Differential
Pull Scale 3 - 9 Lbs 1.4 - 4.0 Kg
Torque Wrench 10 - 30 Lb-in 1.1 - 3.4 N-m
Ring Gear to Pinion Backlash .008" - .012" .23 - .33 mm
Lubrication
AXLE/TORQUE SPECIFICATIONS
P PP P Position osition osition osition osition Gr Gr Gr Gr Grade ade ade ade ade Lb-Ft Lb-Ft Lb-Ft Lb-Ft Lb-Ft N-m N-m N-m N-m N-m Thr Thr Thr Thr Thread ead ead ead ead
Hex Head Fasteners
It It It It Item em em em em
Axle Specifications
Me Me Me Me Metric tric tric tric tric U.S. U.S. U.S. U.S. U.S.
* Pinion bearing preload is established prior to installation of pinion seal.
** Capacity will vary depending on the housing angle in each vehicle. Fill to lower edge of fill hole in rear of axle housing as shown on page 3 .
Pinion Nominal Dimension 3.4725" 88.20 mm
Ring Gear Rivet Pressure 45 - 50 tons 41 - 45 tonnes
Carrier Mounting Bolts 1/2" - 13 8 100 - 120 136 - 162
21
