Parts Listing
79
X510-6
ITEM PART DESCRIPTION
NO. NUMBER
ITEM PART DESCRIPTION
NO. NUMBER
(1) See "Bill of Material Table" on next page
(2) See "Variable Parts Table" within this section
(3) Contact Vehicle Manufacturer
(4) Not Sold Separately
(5) See shim table in the back of this catalog
Jeep Super 35/198 Rear
1 -(3) Housing - Axle Service
2 -(1) Drive Pinion & Gear Assembly
3 41459- (5) Slinger - Variable Thicknesses
4 707162X KIT - Inner Pinion Bearing
5 -(2) Collapsible Spacer
6 706894X KIT - Outer Pinion Bearing
7 -(2) Slinger - Pinion Oil Seal Outer
8 -(2) Seal - Pinion Oil
9 -(2) Seal - Oil
10 -(2) End Yoke/Companion Flange
11 44189 Pinion Nut
12 -(2) Carrier Cover
13 51489 Plug - Carrier Cover
14 34279 Bolt - Carrier Cover (qty 10)
15 38615 RTV Silicone Sealant
16 -(3) Differential Bearing Cap
17 48631-1 Bolt - Differential Bearing Cap
18 706016X KIT - Differential Bearing
19 42104- (5) Diff. Spacer - variable thickness
20 -(1) Case - Differenntial (std)
21 45784-2 Bolt - Drive Gear
22 -(4) Pinion - Differential (std)
41599 Pinion - Differential (t/l)
23 -(4) Gear - Differential (std)
43234 Gear - Differential (t/l)
24 34096 Thrustwasher - Diff Pinion (std)
40266 Thrustwasher - Diff Pinion (t/l)
25 34095 Thrustwasher - Diff Gear (std)
26 44594 Shaft - Differential (std)
42990 Shaft - Differential (t/l)
27 43245 Pin - Shaft Lock
707165X KIT - Diff Plate & Disc (t/l)
(inc items 27, 28, 29, 30, 31)
28 -(4) Plate - Preload Spacer
29 -(4) Disc - Differential
30 -(4) Plate - Differential Pressure
31 40835 Clip - Diff Clutch Retainer
32 -(3) Bolt - Brake Mounting
33 -(3) Nut - Brake Mounting
34 -(2) Retainer Ring - Wheel Bearing
35 -(2) Wheel Bearing Assembly
36 -(2) Seal - Outboard Shaft
37 -(2) Oil Seal Retainer
38 50580 Tone Ring (ABS only)
39 -(1) Shaft - Axle Flanged Drive
40 -(2) C-Clip
