Spicer Jeep Applications 1999-2011 Light Axle Parts - Manual (Page 110)

X510-6
108
Bill of Material Table
Axle Axle Kits Shaft & Joint Assy.
Differential
Bill of
Material
Diff.
Type
Ratio
Ring Gear &
Pinion Kit (7) Case Assy. Kit (8) Case Kit Inner Parts Kit
Right Hand
Shaft Assy.
Left Hand
Shaft Assy.
(7) See Ring Gear & Pinion Kits in XGI Catalog for ratio & tooth combinations.
(8) See Differential Case Assy Kits in XGI Catalog for spline data & ratios.
(9) Serviced with complete differential case assembly kit only.
* Some 2007 JK Wrangler rear axles were produced with components using 7/16”-20 ring gear screws. When servicing one
of these axles, the differential case assembly, ring gear and pinion assembly and ring gear screws must be replaced with
their ½”-20 equivalents. The part numbers listed in the bill of material table are correct for the ½”-20 components.
2007 JK
*2005146-1 Standard 3.21 2007774-5 2008572 - (9) 2009155 2004449-1 2004449-1
*2005146-2 Trac Lok 3.21 2007774-5 2008571 - (9) 2009156 2004449-1 2004449-1
*2005146-3 Standard 4.10 2007772-5 2008572 - (9) 2009155 2004449-1 2004449-1
*2005146-4 Trac Lok 4.10 2007772-5 2008571 - (9) 2009156 2004449-1 2004449-1
*2005147-1 Standard 3.21 2007774-5 2008572 - (9) 2009155 2004449-1 2004449-1
*2005147-2 Standard 4.10 2007772-5 2008572 - (9) 2009155 2004449-1 2004449-1
*2005148-1 Elec Lock 4.10 2007772-5 2008559 - (9) - (9) 2004785-2 2004785-3
*2005149-1 Elec Lock 4.10 2007772-5 2008559 - (9) - (9) 2004785-3 2004785-2
*2006788-1 Standard 3.21 2007774-5 2008572 - (9) 2009155 2004449-1 2004449-1
*2006788-2 Trac Lok 3.21 2007774-5 2008571 - (9) 2009156 2004449-1 2004449-1
*2006788-3 Standard 4.10 2007772-5 2008572 - (9) 2009155 2004449-1 2004449-1
*2006788-4 Trac Lok 4.10 2007772-5 2008571 - (9) 2009156 2004449-1 2004449-1
*2006789-1 Standard 3.21 2007774-5 2008572 - (9) 2009155 2004449-1 2004449-1
*2006789-2 Standard 4.10 2007772-5 2008572 - (9) 2009155 2004449-1 2004449-1
*2006790-1 Elec Lock 4.10 2007772-5 2008559 - (9) - (9) 2004785-2 2004785-3
*2006791-1 Elec Lock 4.10 2007772-5 2008559 - (9) - (9) 2004785-3 2004785-2
*2007024-1 Standard 3.21 2007774-5 2008572 - (9) 2009155 2004449-1 2004449-1
*2007024-2 Trac Lok 3.21 2007774-5 2008571 - (9) 2009156 2004449-1 2004449-1
*2007024-3 Standard 4.10 2007772-5 2008572 - (9) 2009155 2004449-1 2004449-1
*2007024-4 Trac Lok 4.10 2007772-5 2008571 - (9) 2009156 2004449-1 2004449-1
*2007025-1 Standard 3.21 2007774-5 2008572 - (9) 2009155 2004449-1 2004449-1
*2007025-2 Standard 4.10 2007772-5 2008572 - (9) 2009155 2004449-1 2004449-1
*2007026-1 Elec Lock 4.10 2007772-5 2008559 - (9) - (9) 2004785-3 2004785-2
*2007027-1 Elec Lock 4.10 2007772-5 2008559 - (9) - (9) 2004785-3 2004785-2
2008491-1 Standard 3.21 2007774-5 2008572 - (9) 2009155 2004449-1 2004449-1
2008491-2 Standard 4.10 2007772-5 2008572 - (9) 2009155 2004449-1 2004449-1
2008491-3 Trac Lok 3.21 2007774-5 2008571 - (9) 2009156 2004449-1 2004449-1
2008491-4 Trac Lok 4.10 2007774-5 2008571 - (9) 2009156 2004449-1 2004449-1
2008492-1 Standard 3.21 2007774-5 2008572 - (9) 2009155 2004449-1 2004449-1
2008492-2 Standard 4.10 2007772-5 2008572 - (9) 2009155 2004449-1 2004449-1
2008494-1 Elec Lock 4.10 2007772-5 2008559 - (9) - (9) 2004785-3 2004785-2
2007-09 JK
2008493-1 Elec Lock 4.10 2007772-5 2008559 - (9) - (9) 2004785-3 2004785-2
2008 JK
2008674-1 Standard 3.73 2008688-5 2008572 - (9) 2009155 2004449-1 2004449-1
2008675-1 Standard 3.73 2008688-5 2008572 - (9) 2009155 2004449-1 2004449-1
2008676-1 Elec Lock 3.73 2008688-5 2008559 - (9) - (9) 2004785-3 2004785-2
2008677-1 Elec Lock 3.73 2008688-5 2008559 - (9) - (9) 2004785-3 2004785-2
2008809-1 Trac Lok 3.73 2008688-5 2008571 - (9) 2009156 2004449-1 2004449-1
Jeep Super 44 /226 Rear (JK)
