Spicer Jeep Applications 1999-2011 Light Axle Parts - Manual (Page 33)

Variable Parts Listing
X510-6
31
Kits & Parts - Use With All Applications
Description & Item Number (Refer to Bills of Material
"Exploded View" at the front of this section) 2010362 2010363 2011929 2011939 2011940
1 Slinger - Variable Thicknesses 3 41214(5) 41214(5) 41214(5) 41214(5) 41214(5)
2 KIT - Inner Pinion Bearing 4 707064X 707064X 707064X 707064X 707064X
3 Baffle - Pinion Oil 5 48741-3 48741-3 48741-3 48741-3 48741-3
4 Collapsible Spacer 6 50614 50614 50614 50614 50614
5 KIT - Outer Pinion Bearing 7 706015X 706015X 706015X 706015X 706015X
6 Slinger 8 2005565 2005565 2005565 2005565 2005565
7 Seal - Pinion Oil 9 2004670 2004670 2004670 2004670 2004670
8 Oil Seal 10 - - - - -
9 End Yoke/Companion Flange Assy 11 2005008 2005008 2005008 2005008 2005008
10 Pinion Nut 13 44189 44189 44189 44189 44189
11 KIT - Carrier Cover - 2007353 2007353 2007353 2007353 2007353
12 Carrier Cover 14 2004631-2 2004631-2 2004631-2 2004631-2 2004631-2
13 Pinion - Differential (std) 25 2005215 2005215 2005215 2005215 2005215
14 Gear - Differential (std) 26 46502 46502 46502 46502 46502
15 Thrustwasher - Diff Pinion (std) 27 2005202 2005202 2005202 2005202 2005202
16 Thrustwasher - Diff Gear (std) 28 50119 50119 50119 50119 50119
17 Guide Tube 31 2005601 2005601 2005601 2005601 2005601
18 Oil Seal 32 54381 54381 54381 54381 54381
19 KIT - Socket Assembly - 2007354 2007354 2007354 2007354 2007354
20 Socket Assembly (upper) 33 2005838 2005838 2005838 2005838 2005838
21 Socket Assembly (lower) 34 2011892 2011892 2011892 2011892 2011892
22 Dust Slinger 39 51707 51707 51707 51707 51707
23 Washer - Flat 43 - - - - -
24 Hex Nut 44 2002954 2002954 2002954 2002954 2002954
25 Washer - Spring Wave 45 - - - - -
26 Retainer Nut 46 - - - - -
27 Cotter Pin 47 - - - - -
Jeep Super 30 /186 Front (JK & WJ)
(3) Contact Vehicle Manufacturer
(5) See shim table in the back of this catalog
