Parts Listing
15
X510-6
ITEM
PART
DESCRIPTION
NO.
NUMBER
ITEM
PART
DESCRIPTION
NO.
NUMBER
(1) See "Bill of Material Table" on next page
(2) See "Variable Parts Table" within this section
(3) Contact Vehicle Manufacturer
(4) Not Sold Separately
(5) See shim table in the back of this catalog
1
-(3)
Housing - Axle Service
2
-(1)
Drive Pinion & Gear Assembly
3
44035
Slinger - Inner Pinion Bearing
4
706015X KIT - Inner Pinion Bearing
5
32349
Baffle - Pinion Bearing
6
701108X Outer Pinion Bearing Shims
7
706030X KIT - Outer Pinion Bearing
8
13575
Slinger - Outer Pinion Bearing
9
-(2)
Seal - Pinion Oil
10 2-4-6561-1 End Yoke
11
30186
Washer - Pinion Nut
12
30185
Pinion Nut
707180X KIT - Carrier Cover
(inc items 14, 15, 16, 17)
13
40869
Carrier Cover
14
38615
RTV Silicone Sealant
15
43180
Plug - Carrier Cover
16
34279
Bolt - Carrier Cover (qty 10)
17
-(3)
Differential Bearing Cap
18
48631-1 Bolt - Differential Bearing Cap
19 706016X KIT - Differential Bearing
20 701004X Differential Bearing Shims
706937X PKG - Differential Bearing Shim
(inc items 15, 21)
21
-(1)
Case - Differential (std)
22
41221
Bolt - Drive Gear (qty 10)
23
32926
Pinion - Differential (std)
24
33213
Gear - Differential (std)
25
34096
Thrustwasher - Diff Pinion (std)
26
40027
Thrustwasher - Diff Gear (std)
27
41648
Shaft - Differential (std)
28
13449
Lock - Differential Shaft
29
46470
Oil Seal
706944X KIT - Socket Assy (inc 31 thru 36)
30
40584
Slotted Nut
31 500024-6 Cotter Pin
32
40586
Adjusting Split Ring
33
40583
Socket Assembly
34
43682
Nut - Hex Jam / Slotted
35
40916
Socket Assembly
36
-(3)
Nut - Hex Slotted
37
-(3)
Cotter Pin
38
-(3)
Tie Rod Assembly
39
41027
Bolt - Knuckle
40
-(3)
Right / Left Knuckle
41
46849
Slinger - Spindle Yoke (Inner)
42
-(1)
Shaft & Joint Assembly
43
46988
Slinger-Spindle Yoke(Outer,non-ABS)
44
-(3)
Hub Assembly
45
40596
Washer - Flat
46
40597
Nut - Hex
47
45749
Sprint - Wave Washer
48
40598
Nut - Retainer
49 500025-10 Cotter Pin
50
44646
Tone Ring (ABS only)
Jeep 30 /181 Front
