Bearing adjustment shims – Spicer Jeep Applications 1999-2011 Light Axle Parts User Manual
Page 113
X510-6
111
Bearing Adjustment Shims
30207
MM Inch
30207-1(1) 0.08 .003
30207-2(1) 0.13 .005
30207-3(2) 0.25 .010
30207-4(2) 0.76 .030
(1) Qty 6 Included in 701108X
(2) Qty 4 Included in 701108X
30210
MM Inch
30210-1(1) 0.08 .003
30210-2(2) 0.13 .005
30210-3(3) 0.25 .010
(1) Qty 8 Included in 701010X
(2) Qty 6 Included in 701010X
(2) Qty 4 Included in 701010X
30214
MM Inch
30214-1*
0.08 .003
30214-2*
0.13 .005
30214-3*
0.25 .010
30214-4*
0.76 .030
*Qty 4 Included in 701005X
30215
MM Inch
30215-1*
0.08 .003
30215-2*
0.13 .005
30215-3*
0.25 .010
30215-4*
0.76 .030
*Qty 4 Included in 701004X
30215
MM Inch
31402-1(1) 0.08 .003
31402-2(2) 0.13 .005
31402-3(2) 0.25 .010
31402-4(2) 0.76 .030
(1) Qty 4 Included in 701121X
(2) Qty 2 Included in 701121X
Part
Number
Thickness
Part
Number
Thickness
Part
Number
Thickness
41459
MM Inch
41459-1*
0.76 .030
41459-2
0.79 .031
41459-3*
0.81 .032
41459-4
0.84 .033
41459-5*
0.86 .034
41459-6
0.89 .035
41459-7*
0.91 .036
41459-8
0.94 .037
41459-9*
0.97 .038
41459-10 0.99 .039
41459-11* 1.02 .040
41459-12 1.04 .041
41459-13* 1.07 .042
41459-14 1.09 .043
41459-15* 1.12 .044
41459-16 1.14 .045
41459-17* 1.17 .046
41459-18 1.19 .047
41459-19* 1.22 .048
41459-20 1.24 .049
41459-21* 1.27 .050
41459-22 1.30 .051
41459-23* 1.32 .052
41459-24 1.35 .053
41459-25 1.37 .054
41459-26 0.51 .020
41459-27 0.63 .021
*Included in 701130X
42104
MM Inch
42104-1*
3.66 .144
42104-2
3.68 .145
42104-3*
3.71 .146
42104-4
3.73 .147
42104-5*
3.76 .148
42104-6
3.78 .149
42104-7*
3.81 .150
42104-8
3.84 .151
42104-9*
3.86 .152
42104-10 3.89 .153
42104-11* 3.91 .154
42104-12 3.94 .155
42104-13* 3.96 .156
42104-14 3.99 .157
42104-15* 4.01 .158
42104-16 4.04 .159
42104-17* 4.06 .160
42104-18 4.09 .161
42104-19* 4.11
.162
42104-20 4.14 .163
42104-21* 4.17 .164
42104-22 4.19 .165
42104-23* 4.22 .166
42104-24 4.24 .167
42104-25* 4.27 .168
42104-26 4.29 .169
42104-27* 4.32 .170
42104-28 4.34 .171
42104-29* 4.37 .172
42104-30 4.39 .173
42104-31* 4.42 .174
42104-32 4.45 .175
42104-33 4.47 .176
42104-34 4.50 .177
42104-35 4.52 .178
42104-45 4.55 .179
42104-46 4.57 .180
42104-47 4.60 .181
42104-48 4.62 .182
42104-49 4.65 .183
* Included in 73139X
41214
MM Inch
41214-6(4)
0.89 .035
41214-7(4)
0.91 .036
41214-8(4)
0.94 .037
41214-9(4)
0.97 .038
41214-10(4) 0.99 .039
41214-11(3)* 1.02 .040
41214-12(3) 1.04 .041
41214-13(3)* 1.07 .042
41214-14(3) 1.09 .043
41214-15(3)* 1.12 .044
41214-16(2) 1.14 .045
41214-17(2)* 1.17 .046
41214-18(2) 1.19 .047
41214-19(2)* 1.22 .048
41214-20(2) 1.24 .049
41214-21(1)* 1.27 .050
41214-22(1) 1.30 .051
41214-23(1)* 1.32 .052
41214-24(1) 1.35 .053
41214-25(1)* 1.37 .054
*Included in 701140X
(1) Included in 72922-5X
(2) Included in 72922-4X
(3) Included in 72922-3X
(4) Included in 72922-2X
41316
MM Inch
41316-1*
0.36 .014
41316-2*
0.38 .015
41316-3*
0.41 .016
41316-4*
0.46 .018
41316-5*
0.51 .020
41316-6*
0.53 .021
41316-7*
0.56 .022
41316-8*
0.58 .023
41316-9*
0.76 .030
* Included in 72921X
Part
Number
Thickness
Part
Number
Thickness
Part
Number
Thickness
Part
Number
Thickness
Part
Number
Thickness
Part
Number
Thickness
