Spicer Jeep Applications 1999-2011 Light Axle Parts - Manual (Page 43)

Variable Parts Listing
X510-6
41
Kits & Parts - Use With All Applications
Description & Item Number (Refer to Bills of Material
"Exploded View" at the front of this section)
Jeep Super 30 /186 Front (JK & WJ)
611099 611100 611117 611118 611119
1 Slinger - Variable Thicknesses 3 49634 (5) 49634 (5) 49634 (5) 49634 (5) 49634 (5)
2 KIT - Inner Pinion Bearing 4 706015X 706015X 706015X 706015X 706015X
3 Baffle - Pinion Oil 5 - - - - -
4 Collapsible Spacer 6 50576 50576 50576 50576 50576
5 KIT - Outer Pinion Bearing 7 706894X 706894X 706894X 706894X 706894X
6 Slinger 8 13575 13575 13575 13575 13575
7 Seal - Pinion Oil 9 47761 47761 50531 50531 50531
8 Oil Seal 10 47762 47762 47762 47762 47762
9 End Yoke/Companion Flange Assy 11 2-1-2891(3) 2-1-2891(3) 2-4-8571-1(3) 2-4-8571-1(3) 2-1-2891(3)
10 Pinion Nut 13 50560 50560 50560 50560 50560
11 KIT - Carrier Cover - 707486X 707486X 707486X 707486X 707486X
12 Carrier Cover 14 47832-1 47832-1 47832-1 47832-1 47832-1
13 Pinion - Differential (std) 25 32926 32926 32926 32926 32926
14 Gear - Differential (std) 26 33213 33213 33213 33213 33213
15 Thrustwasher - Diff Pinion (std) 27 34096 34096 34096 34096 34096
16 Thrustwasher - Diff Gear (std) 28 40027 40027 40027 40027 40027
17 Guide Tube 31 - - - - -
18 Oil Seal 32 46470 46470 46470 46470 46470
19 KIT - Socket Assembly - 707488X 707488X 707488X 707488X 707488X
20 Socket Assembly (upper) 33 40916 40916 40916 40916 40916
21 Socket Assembly (lower) 34 48715 48715 48715 48715 48715
22 Dust Slinger 39 - - - - -
23 Washer - Flat 43 40596 40596 40596 40596 40596
24 Hex Nut 44 40597 40597 40597 40597 40597
25 Washer - Spring Wave 45 45749 45749 45749 45749 45749
26 Retainer Nut 46 40598 40598 40598 40598 40598
27 Cotter Pin 47 500025-10 500025-10 500025-10 500025-10 500025-10
(3) Contact Vehicle Manufacturer
(5) See shim table in the back of this catalog
