Spicer Jeep Applications 1999-2011 Light Axle Parts - Manual (Page 111)

X510-6
(7) See Ring Gear & Pinion Kits in XGI Catalog for ratio & tooth combinations.
(8) See Differential Case Assy Kits in XGI Catalog for spline data & ratios.
(9) Serviced with complete differential case assembly kit only. 109
Bill of Material Table
Axle Axle Kits Shaft & Joint Assy.
Differential
Bill of
Material
Diff.
Type
Ratio
Ring Gear &
Pinion Kit (7) Case Assy. Kit (8) Case Kit Inner Parts Kit
Right Hand
Shaft Assy.
Left Hand
Shaft Assy.
2010 JK
2011958-1 Standard 3.21 2007774-5 2008572 - (9) 2009155 2004449-1 2004449-1
2011958-2 Standard 3.73 2008688-5 2008572 - (9) 2009155 2004449-1 2004449-1
2011958-3 Trac Lok 3.21 2007774-5 2008571 - (9) 2009156 2004449-1 2004449-1
2011958-4 Trac Lok 3.73 2008688-5 2008571 - (9) 2009156 2004449-1 2004449-1
2011959-1 Standard 3.21 2007774-5 2008572 - (9) 2009155 2004449-1 2004449-1
2011959-2 Standard 3.73 2008688-5 2008572 - (9) 2009155 2004449-1 2004449-1
2011961-1 Elec Lock 4.10 2007772-5 2008559 - (9) - (9) 2004785-3 2004785-2
2011962-1 Elec Lock 4.10 2007772-5 2008559 - (9) - (9) 2004785-3 2004785-2
2011963-1 Elec Lock 3.73 2008688-5 2008559 - (9) - (9) 2004785-3 2004785-2
2011 JK
2011960-1 Elec Lock 3.73 2008688-5 2008559 - (9) - (9) 2004785-3 2004785-2
Jeep Super 44 /226 Rear (JK)
