Spicer Jeep Applications 1999-2011 Light Axle Parts - Manual (Page 30)

Description & Item Number (Refer to Bills of Material
"Exploded View" at the front of this section)
Variable Parts Listing
X510-6
28
Kits & Parts - Use With All Applications
2001204 2001205 2001246 2001247 2005185
1 Slinger - Variable Thicknesses 3 49634(5) 49634(5) 49634(5) 49634(5) 41214(5)
2 KIT - Inner Pinion Bearing 4 706015X 706015X 706015X 706015X 707064X
3 Baffle - Pinion Oil 5 - - - - 48741-3
4 Collapsible Spacer 6 50576 50576 50576 50576 50614
5 KIT - Outer Pinion Bearing 7 706894X 706894X 706894X 706894X 706015X
6 Slinger 8 13575 13575 13575 13575 42778
7 Seal - Pinion Oil 9 50531 50531 50531 50531 2004670
8 Oil Seal 10 48862 48862 48862 48862 -
9 End Yoke/Companion Flange Assy 11 52917 52917 2-4-8571-1(3) 2-4-8571-1(3) 2005008
10 Pinion Nut 13 50560 50560 50560 50560 44189
11 KIT - Carrier Cover - 707486X 707486X 707486X 707486X 707274X
12 Carrier Cover 14 47832-1 47832-1 47832-1 47832-1 40869-1
13 Pinion - Differential (std) 25 46504 - 46504 - 2005215
14 Gear - Differential (std) 26 46502 - 46502 - 46502
15 Thrustwasher - Diff Pinion (std) 27 34096 - 34096 - 2005202
16 Thrustwasher - Diff Gear (std) 28 40027 - 40027 - 50119
17 Guide Tube 31 - - - - 2003626
18 Oil Seal 32 46470 46470 46470 46470 46470
19 KIT - Socket Assembly - 707488X 707488X 707488X 707488X 2007354
20 Socket Assembly (upper) 33 40916 40916 40916 40916 2005838
21 Socket Assembly (lower) 34 48715 48715 48715 48715 2011892
22 Dust Slinger 39 - - - - 51707
23 Washer - Flat 43 40596 40596 40596 40596 -
24 Hex Nut 44 40597 40597 40597 40597 2002954
25 Washer - Spring Wave 45 45749 45749 45749 45749 -
26 Retainer Nut 46 40598 40598 40598 40598 -
27 Cotter Pin 47 500025-10 500025-10 500025-10 500025-10 -
Jeep Super 30 /186 Front (JK & WJ)
(3) Contact Vehicle Manufacturer
(5) See shim table in the back of this catalog
