EN- 3000 Series Indicators
.2 Overview of Parts and Controls (Cont.)
Item Description
1 Keypad Connector J8
2 Battery Connector
3 Lne Power Input
4 Sense Jumper W2
5 Load Cell Termnal Block J5
6 Sense Jumper W1
7 RS232 Termnal Block J7
8 LFT On / Off Swtch
TABLE -2. MAIN PC BOARD.
Fgure 1-2. Man PC Board.
1 2 3 4 7 5 6
8
J8 J1
J5
J7
W1
W2
J2
GND
LFT OFF
RXD -EXE -SEN -SIG CGND +SIG
LFT ON
+SEN TXD +EXE
TXD GND
RXD
+EXC +SIG -SIG -EXC
+SENS GND -SENS
LOAD CELL WIRING
RS232 WIRING
