RMC 5015
1U Rackmount System
Clock-Spread Spectrum
Select Enable to use the feature of Clock Spectrum, which will allow the BIOS to monitor and attempt
to reduce the level of Electromagnetic Interference caused by the components whenever needed. The
options are Disabled and Enabled. If this feature is set to Enabled, the following items will display:
XIDE Configuration
When this submenu is selected, the AMI BIOS automatically detects the presence of the IDE Devices
and displays the following items:
ATA/IDE Configuration
This feature allows the user to configure ATA/IDE settings. The options are Disabled and Enhanced.
Configure SATA as
Please choose IDE if the installed hard disk(s) are to be configured as independent devices
and will be used normally.
Choose RAID if you have more than one drive installed and will be used in a Redundant Array
(RAID) configuration.
Note: Please use the Intel Matrix Storage Manager (option ROM) to con- figure your RAID by
pressing and holding down and pressing (the "i" key) during POST. For a
downloadable PDF manual.
Select AHCI for advanced SATA features such as hot-plugging and native command queueing.
Note: Take caution when using AHCI, as your operat- ing system may need drivers to match this
configuration. This feature is for technicians only.
The options are IDE, RAID and AHCI.
Configure SATA Channels
The options are Before PATA and Behind PATA.
Primary IDE Master/Slave, Secondary IDE Maser/Slave and Third IDE Maser/ Slave
These settings allow the user to set the parameters of Primary IDE Master/Slave, Secondary IDE
Master/Slave and Third IDE Master/Slave slots. Hit to
