RMC 5015

1U Rackmount System

1-3

Server Chassis Features

The following is a general outline of the main features of the RMC5015 1U mini rackmount server
chassis.

System Power

The RMC5015 chassis includes a single 200W power supply.

SATA Subsystem

The RMC5015 chassis was designed to support one 3.5" or two 2.5" internal SATA drives (not hot-
swappable). ATA/100 IDE drives can be alternately sup- ported.

Note: The operating system you use must have RAID support to enable the hot- swap capability of the
SATA drives (RAID 0, 1, 5 and 10 supported).

Control Panel

The control panel on the RMC5015 provides important system monitoring and control information.
LEDs indicate power on, network activity, hard disk drive activity and system overheat. The control
panel also includes a main power button and a system reset button as well as two

Rear I/O Panel

The rear I/O panel on the RMC5015 provides one COM port, two USB ports, PS/2 mouse and key-
board ports, a graphics port and two Gb Ethernet ports.

Expansions Cards

The RMC5015 supports the use of one full-height, half length PCI expansion card.
