Appendices
User Guide Page 5
Appendix B: Icons
ICON Description
Main Menu Icons
RAIDGuard X Server icon – The icon that is on the
desktop and notification area
Add / Delete a controller – Select the controller to
administer
Create / Delete an array – Change the arrays within the
RAID system.
Preferences – Activate alarms, mode settings, cache
settings, password, and controller card time.
Email – Set the addresses to send e-mail alerts to.
Option – Set the Slice, expansion, migration, health, disk
locking, LUNs, and take a snapshot of the array.
Option Menu Icons
Slicing an array into several parts
LUN Map – Assign a LUN to a slice
Expand an array to larger capacity by adding disks
Migrate from one RAID level to another target RAID level
Snapshot – Create a backup of a slice
Health Center – Repair / Maintain arrays
Unlock – Fix locked drives
Application Icons
Drive icon
Drive belongs to Array 1, 2, 3, 4
A drive being deleted in Array 1, 2, 3, 4
A JBOD drive being selected
JBOD being deleted
A drive being selected
An offline drive
A locked drive
