F0Z0218m fig. 186 F0G0077m fig. 187
Changing the rear window wiper blade fig. 187
Proceed as follows:
❒ raise the cover A and remove the arm from the car,
slackening the nut B that fastens it to the pivot pin;
❒ position the new arm correctly and tighten the nut;
❒ lower the cover.
Changing the windscreen wiper blades fig. 186
Proceed as follows:
❒ lift the arm A of the wiper and position the blade so that
it forms an angle of 90° with the arm;
❒ press tab B of the coupling spring and remove the blade
to be replaced from the arm A;
❒ fit the new blade by inserting the tab into the special
slot in the arm. Make sure it is properly locked into
place.
