F0Z0696m fig. 130
F0Z0603m fig. 129
❒ fully tighten the bolts, passing alternatively from a bolt
to the opposite one, following the order shown in
fig. 130.
REFITTING THE STANDARD WHEEL
❒ Following the above procedure, raise the car and re-
move the space-saver wheel;
❒ make sure the contact surfaces between wheel and hub
are clean so that the fastening bolts will not come loose;
❒ fit the standard wheel by inserting the first bolt L-
fig. 128 into the hole close to the inflation valve;
❒ fit the wheel cup making the symbol C coincide with
the inflation valve and the bolt previously fastened to
the hole M-fig. 129;
❒ fasten the three other bolts with the wrench provided;
❒ lower the car and remove the jack;
F0Z0233m fig. 128
