F0Z0092m fig. 144 F0Z0094m fig. 146
F0Z0093m fig. 145
❒ remove the burnt bulb F-fig. 144 and fit the new one;
❒ refit by reversing the above mentioned operations.
To replace the main/dipped beam light bulb, proceed as
follows:
❒ release the clip A-fig. 141 and remove the cap B;
❒ remove the connector G-fig. 145;
❒ release the bulb-holder clip H-fig. 145;
❒ remove the burnt bulb I-fig. 146 and fit the new one;
❒ refit by reversing the above mentioned operations.
