Hama MF110 - Manual (Page 9)

ENGLISH
Step 7: Cable/Wire Management
CAUTION: Do not run cables through a pinch point.
Before beginning cable management pull the television into the position as far from the wall as possible. Leave some slack
in the cables so that during motion so there is no added tension on the connectors. Wire Tie Clips (R) can be attached to the
holes in the top and the bottom of the Arm Assembly (B) by simply pressing them into place as shown in the Detailed View
of Diagram 7. Wire Ties (T) can then be added to the Wire Tie Clips.
Diagram 7 Detailed View
Sanus Systems 2221 Hwy 36 West, Saint Paul, MN 55113 05.10.06 (100044)
Customer Service: 800.359.5520. See complementary Sanus products at www.sanus.com
B
R
