58
AuthP/AuthQ Input the AuthP/AuthQ provided by DHIS here.
(This field appears only when the authentication type
is “QRC”).
Click “Apply” to save the changes, or click “Cancel” to discard the changes. After you have
clicked “Apply”, you will see the following message:
Click “Apply” to save the changes and restart the broadband router. It takes about 60
seconds for the broadband router to restart. Click “Continue” to configure other settings.
3‐5‐3 Port Forwarding
The port forwarding function allows you to redirect the ports of an Internet IP address to
corresponding ports of an IP address in the local network. The port number(s) of the
Internet IP address and the local IP address must be identical. If not, please use the virtual
server function.
Item Name Description
Enable Port Forwarding Check this box to enable the port forwarding function.
Private IP Input the IP address of the computer in the local
network that provides the Internet service.
Computer Name Computer names found in the local network are listed
here. You can select a computer name and click the
“<<” button to add the selected computer’s IP
address to the “Private IP” field.
Type Select the connection type (TCP or UDP) here. If you
are not sure, please select “Both”.
Port Range Input the starting port number in the left field and the
