27
Item Name Description
Fixed IP Address Input the IP address assigned by your ISP here.
Subnet Mask Input the subnet mask assigned by your ISP here.
DNS Address 1
and 2 Enter the primary and secondary DNS addresses assigned by
your ISP here.
Default Gateway Input the default gateway assigned by your ISP here. Some
ISPs may call this “Default Route”.
TTL Enable the “TTL” function if your ISP requires you to do so.
NOTE: You must use the addresses provided by your ISP. Inputting incorrect values
will cause malfunction.
Click “Apply” to save the changes. After you have clicked “Apply”, you will see the following
message:
Click “Apply” to save the changes and restart the broadband router. It takes about 60
seconds for the broadband router to restart. Click “Continue” to configure other settings.
3‐2‐3 PPPoE
If your ISP is providing you Internet access via PPPoE (Point‐to‐Point Protocol over Ethernet),
select “PPPoE”.
