47
Item Name Description
Band Select from one of the following options:
2.4GHz (B): Allows 802.11b wireless network clients
to connect to this router.
2.4GHz (N): Allows 802.11n wireless network clients
to connect to this router.
2.4GHz (B+G): Allows 802.11b and 802.11g wireless
network clients to connect to this router.
2.4GHz (G): Allows 802.11g wireless network clients
to connect to this router.
2.4GHz (B+G+N): Allows 802.11b, 802.11g, and
802.11n wireless clients to connect to this router
(recommended).
ESSID This is the name of your router. You can type any
alphanumerical character here (maximum 32
characters).
Channel Number Select a channel from the dropdown menu. All access
points must use the same channel (1 to 13).
Associated Clients Click “Show Active Clients” for the list of all
connected wireless clients. Click “Refresh” in the
new window to renew the list, and click “Close” to
close the window.
Note: If you have a pop‐up blocker installed, you
may have to disable it, or set it to allow the pop‐up
window to show up.
Root AP SSID Input the SSID of the wireless access point with
which you wish to connect.
Site Survey Click “Select Site Survey” and a pop‐up window will
appear. All reachable wireless access points will be
shown in the window. Select a wireless access point
from the list, and click “Done” to establish a
connection. Clicking “Refresh” will renew the list.
Wireless Module Select “Enable” to turn on the 2.4GHz wireless
signal and select “Disable” to turn it off.
