Amplifier Probe and Tone Generator
Amplifier Probe
■
Identifies and traces wire or cables within a group
■ Battery low indicator
Tone Generator
■ Emits three different types of tones
■ Auto-off after three hours of non-use
■ F-Connector port for toning & tracing coaxial CATV cabling
systems
■ Tone can be added in any status
Description Cat. No.
Amplifier Probe 62-164
Tone Generator 62-160
Amplifier Probe & Tone Generator Kit - includes 62-164, 62-160,
Lead Set, Cable Assembly & Standard Replacement Tip
33-864
TRACETone™ Tone Generator &
Amplifier Probe
■
Test continuity and locate signal
of installed wire and cable
■ Two selectable tone styles
■ Tone Generator & Amplifier
Probe fit together for easy storage
■ Extra-deep serrations grip wire better
■ RJ-11 Alligator Clip, RJ-11 Cable Assembly included
Description Cat. No.
TRACETone™ Tester and Accessories 62-140
VDV MultiMedia Cable Tester
Easy-to-use tester for installers working
with voice, data and video applications.
One tester for all applications!
■ Voice — supports 3-pair USOC
and 6-position RJ-11/12 jacks for
telephone cable testing
■ Data — supports both shielded and
unshielded cable testing to T568A/B
(RJ-45)
■ Video — tests coax cable for opens
and shorts with F-connector interface
■ Tests for opens, shorts, miswires,
reversals and split pairs. Also indicates
correct wiremap. Has automatic shut
off (to prolong battery life) and low
battery indicator.
■ Easy-to-read LCD display with “PASS/FAIL” indicator after each
test
■
Tone generator supports four different tones making fault isolation
easier
■ One remote wiremap and testing unit is stored inside tester —
easier to keep all parts together
■ Uniquely designed remote accommodates RJ-11, RJ-45 and
F-style connectors
Description Cat. No.
Kit with integrated remote and accessories 33-856
Smart6™ Modular Tester
■
6-position Tester
■ Incoming call identification
Description Cat. No.
Smart6™ Modular Tester 62-096
LinkMaster™ Tester
Tests wiring configurations on
UTP/STP cables. Checks for
shorts, miswires, reversals and
split pairs. Debug feature,
automatic shut-off and low
battery LED indication.
■
Designed to test installed
twisted pair wiring
■ Tests unshielded and shielded
modular plugs
■ Main unit and remote allow one
person testing
Description Cat. No.
LinkMaster™ Tester and Remote 62-200
NEW
Design
NEW
Design
62-164 62-160
33-916 33-917
Also available in these kits:
