Coaxial Selection Chart
DataComm Equipment
1-800-435-0705 for Customer Service www.idealindustries.com G-29
Coaxial Selection Chart
Compression Style
Crimp Style
Cable Cutter Stripper Compression Tool Compression Connector Tester
CATV/SATV/F-type
RG-59
45-074, 45-075 45-265, 45-603, 45-526 30-603, 30-793, 30-633 92-610, 92-619
Reg/Tri/Quad
RG-6
45-074, 45-075 45-262, 45-603, 45-526 30-603, 30-793, 30-633
92-654, 92-651, 92-650,
Reg/Tri/Quad 92-656, 92-659
RG-6 Plenum 45-074, 45-075 45-282, 45-603, 45-526 30-603, 30-793, 30-633 92-660, 92-669
RG-11 45-074, 45-075 45-111, 45-510 30-603, 30-793 89-211, 89-1211
Minis 45-074, 45-075 45-529, 45-163 30-603, 30-793 89-014SM, 89-014SMRCA
BNC
RG-59 45-074, 45-075 45-265, 45-603, 45-526 30-793 89-047, 89-5047
RG-6 45-074, 45-075 45-265, 45-603, 45-526 30-793 89-048, 89-5048
*Need LA-4173 adapter.
Cable Cutter Stripper Crimping Tool Connector Tester
CATV/SATV/F-Type
RG-59 45-074, 45-075 45-265, 45-603, 45-320 30-503 85-036, 85-016, 86-016
RG-6 45-074, 45-075 45-262, 45-603, 45-320 30-503 85-037, 85-017, 86-017
RG-6 Quad Shield 45-074, 45-075 45-282, 45-603, 45-320 30-503 85-057, 85-030, 86-030
RG-6 Plenum 45-074, 45-075 45-282, 45-603 30-503 N/A
RG-11 45-074, 45-075 45-164, 45-510, 45-111 30-482 N/A
BNC
RG-59, Non-Plenum 45-074, 45-075 45-520 30-502, 30-483 85-513, 85-517, 85-502
RG-6 Non-Plenum 45-074, 45-075 45-520 30-483 85-545
*Need LA-4173 adapter.
33-856, 33-880
33-881, 33-887*
33-856, 33-880
33-881, 33-887*
