35-495
110 Blade
Punch Down Tools
35-485
35-492
35-185
Impact Turn-Lock™ Punch Down Tools Cat. No.
Punchmaster™ II Punch Down Tool - body only 35-483
Punchmaster™ II Punch Down Tool w/110 blade 35-485
Punchmaster™ II Punch Down Tool w/66 blade 35-487
Non-Impact Turn-Lock™ Punch Down Tools Cat. No.
Punch Down Tool w/110 blade 35-492
Punch Down Tool w/66 blade 35-493
Economy Punch Down Tool Cat. No.
Non-impact Tool w/permanent non-cut blade 35-185
35-407
110/66 Blade
35-497
66 Blade
35-478
Krone ® Blade
35-479
Bix ® Blade
Removable Blades* Cat. No.
110 Turn-Lock™ blade 35-495
66 Turn-Lock blade 35-497
110/66 combo blade w/cutting edges 35-407
Krone ® blade 35-478
Bix ® blade 35-479
*Not applicable for Economy Punch Down tool.
Bix ® is a registered trademark of Nortel. Krone ® is a registered trademark of Krone, Inc.
Kit Tool Only
Description Cat. No. Cat. No.
Tool for RJ-11 (1, 2, 3 pair) and RJ-45 (4 pair) Plugs 33-700* 30-496
Tool for RJ-45 (4 pair) & DECconnect MMJ (RJ-11, 3 pair) N/A 30-497
Tool for RJ-11 (1, 2, 3 pair) & DECconnect MMJ
(RJ-11, 3 pair)
N/A 30-498
Tool for RJ-22 (handset) and RJ-11 (1, 2, 3 pair) N/A 30-499
Replacement Cut and Strip Blade Set for Telemaster™ N/A LB-1747
Kit includes 10 each, RJ-45 8P8C, RJ-11 6P6C and RJ-11 6P4C modular plugs.
Telemaster™ Telephone Tools
■
For paired conductors
■
Multi-function telephone
tool cuts, strips and crimps
for easy one-tool application
■ Steel frame for long-term durability. (Crimps primary modular
plug strain relief only)
■
For paired conductors
■
Ratchet version of popular
Telemaster™ Tool for RJ-45
and RJ-11 modular plugs
■
Repeatable crimp action for
consistent, high quality connections
Ratchet Telemaster™
Description Cat. No.
Ratchet Telemaster™ 30-696
Replacement Cut & Strip Blade Set for 30-696 LA-4102
Modular Plug Tool Kit
■
Multi-function telephone/network
tool; cuts, strips and crimps
■
Steel frame construction
for durability
■ Interchangeable dies allow for
crimping RJ-45 and RJ-11 modular plugs
■ Tool-less die change for added convenience
■ Spring return handle for comfort
Description Cat. No.
Modular Plug Tool Kit 33-296
33-505
33-704 33-750
33-705
Also available in these kits:
Also available in these kits:
