Connectors
DataComm Equipment
1-800-435-0705 for Customer Service www.idealindustries.com G-21
BNC Coaxial Connectors
IDEAL coaxial connectors are available in two grades. A premium specification grade features precision machined brass bodies with nickel
plating. The commercial grade consists of machined diecast components with nickel plating. A variety of connectors handle different
termination types, cable size, impedance rating and attachment means.
■ Connector construction covers both plenum and non-plenum cable jackets
■ Captive gold center contacts provide maximum conductivity and minimal resistance
■ Nickel plating resists corrosion, tarnish and ensures signal quality
■ Meets military specifications. MS39012 and MIL202 where applicable.
■ Available in both small and bulk quantities to suit a range of application requirements
Connector Cable Center Connector Connector
Type Type Conductor Jacket Impedance Grade Insulation Model Qty. Cat. No.
Commercial IA-3620 Bag of 5 85-490
BNC Plug RG-58 20 AWG Solid Non- 50 Ohm Delrin
Plenum
Specification IA-3621 Bag of 5 85-491
Non-
IA-3617
Bag of 5 85-502
Plenum
Box of 100 86-502
Plenum IA-3618 Bag of 5 85-512
BNC Plug
Non-
IA-3624 Bag of 5 85-513
Plenum
Plenum IA-3626 Bag of 5 85-515
Non-
50 Ohm Specification IA-3592 Bag of 5 85-517
Plenum
RG-6 18 AWG Solid IA-3634 Bag of 5 85-545
Belden
20 AWG Solid IA-3636 Bag of 5 85-550
8281
BNC Jack RG-59 22-23 AWG Solid
Non-
75 Ohm Specification Teflon IA-3638 Bag of 5 85-553
Plenum
BNC
— — — 50 Ohm Specification Delrin IA-3641 Bag of 5 85-556
Terminator
BNC Tee
— Jack to Plug — 50 Ohm Commercial Delrin IA-3667 Bag of 5 85-588
Adapter
BNC Adapter — Jack to Jack — 50 Ohm Specification Delrin IA-3668 Bag of 5 85-590
BNC
RG-59 22-23 AWG Solid
Non-
50 Ohm Commercial Delrin IA-3677 Bag of 5 85-480
Twist-on Plug Plenum
BNC Plug
BNC Plug
20 AWG Solid
22-23 AWG Solid
RG-59
Non-
Plenum
75 Ohm
75 Ohm Commercial
Specification Delrin
Delrin
