DATA COMM G 45-339 - Manual (Page 11)

30-587
RG-58, RG-174 and RG-8218 for both
50 and 75 ohm cables (Hex 0.213
(5.41mm), 0.178 (4.52mm), 0.068
(1.73mm), 0.042 (1.07mm)
Tool w/die N/A
30-591
Plenum and Non-Plenum Thinwire
Cables RG-58 and 59 (Hex, 0.213
(5.41mm), 0.190 (4.83mm), 0.068
(1.73mm), 0.042 (1.07mm)
Tool w/die N/A
30-593
Mini UHF and BNC/TNC 5 cavity
(Hex, 0.052 (1.32mm), 0.068 (1.73mm),
0.100 (2.54mm), 0.213 (5.41mm),
0.255 (6.48mm)
Tool w/die N/A
30-594
Fully Insulated quick disconnect
terminals with thinner wire barrels
22-10 AWG (.324mm
2 - 5.261mm 2 )
Tool w/die N/A
30-599
30-18 AWG (.205mm
2 - 2.08mm 2 )
Open Barrel Pins and Sockets
Tool w/die N/A
30-479 (Tool w/die)
For insulated terminals, 22-10 AWG
with built-in locator
30-556
RJ-11 Crimp Tool for two, four or
six-position modular plugs
Tool w/die N/A
30-559
RJ-45 Eight-position Crimp Tool
for keyed or non-keyed modular
plugs
Tool w/die 30-522
30-560
RJ-45 Eight-position Crimp Tool
for AMP RJ-45 modular plugs
Tool w/die 30-521
30-570
RG-6, RG-174, Belden-Type
RG-8281 cables (Hex. 0.324
(8.23mm), 0.178 (4.52mm),
0.068 (1.73mm)
Tool w/die N/A
30-572
16-26 AWG (1.31mm
2 - .128mm 2 )
miniature insulated rings, spade
and butt splices
Tool w/die N/A
30-573
Cambridge CP-88, CP-89 BNC/TNC
coax connectors with RG-58,
RG-59/RG-62 AU cables (Hex 0.305
(7.75mm), 0.068 (1.73mm), 0.228
(5.79mm)
Tool w/die 30-481
30-576
RG-174, Mini 59 BNC/TNC
Connectors (Hex, 0.178 (4.52mm),
0.128 (3.25mm), 0.068 (1.73mm)
Tool w/die 30-485
DataComm Equipment
Crimpmaster™ Crimp Tools & Die Sets
Crimp T
ools/
Die Sets
1-800-435-0705 for Customer Service www.idealindustries.com G-11
Dies change quickly and easily
with a screwdriver.
Interchangeable dies
provide versatility
in a single tool
Pressure adjustment
for actuation force
Ratchet crimp action
provides repeatable and
reliable terminations
Crimp release provides
operator safety
High quality ratchet-type crimp tool for electricians, contractors and installers who require guaranteed repeatability of good mechanical and
electrical connections.
Description Cat. No.
Crimpmaster™ Crimp Tool Frame 30-506
30-577
N-Series and RG-8/11 Connectors
(Hex, 0.429 (10.90mm), 0.100
(2.54mm), 0.080 (2.03mm)
Tool w/die 30-482
30-578
RG-59, RG-6, and 8281 50 and 75
OHM cables (Hex, 0.324(8.23mm),
0.255 (6.48mm), 0.068 (1.73mm),
0.042 (1.07mm)
Tool w/die 30-483
30-579
22-10 AWG (.324mm
2 - 5.261mm 2 )
insulated terminals/color coded
nests
Tool w/die 30-500
30-580
22-8 AWG (.3mm
2 - 8mm 2 )
non-insulated terminals
Tool w/die N/A
30-581
RG-58, RG-59/62, BNC/TNC Coax
Connectors (Hex, 0.255 (6.48mm),
0.213 (5.41mm), 0.068 (1.73mm)
Tool w/die 30-502
30-582
F-type CATV RG-59, RG-6
Connectors (Hex, 0.350 (8.89mm),
0.320 (8.13mm), 0.255 6.48mm)
Tool w/die 30-503
30-586
22-12 AWG (.324mm
2 - 3.31mm 2 )
Non Insulated Open Barrel
Connectors, Commercial Type
Tool w/die N/A
Also available in these kits:
33-400 33-917
Section G - DataComm 10/22/08 8:21 AM Page 11
