Lite-Strip™
Optical Fiber Stripper
V-notch blades strip a wide range of
outer cable jacket. Precision-ground,
replaceable knife-type blades strip
tight buffer tube insulations
(900µm). Also strips
mechanically strippable
coatings from 250
microns to 900
microns.
■
Replaceable precision-ground blades cleanly strip buffer
coatings
■ New funneled hole makes cable insertion easier
■ Improved spring mounting returns handles to original position
after every application
■ One-step, 900 micron stripping hole provides broader
stripping range
■ Extra durable to withstand normal drops without requiring
tool realignment
■ New gauge color makes fiber and hole identification easier
■ Improved comfort-grip handles for an easier, more comfortable
stripping process
Description Fiber Sizes Cat. No.
Lite-Strip ™ Optical Fiber Stripper (900µm/250µm) 125µm, 140µm 45-350
Split-Tip Fiber Optic Swabs
Polishing Films for Fiber
Optic Connectors
■ Split-tip design cleans fiber easier
and more efficiently than other
methods
■ Tube/handle is pre-loaded
with 99% isopropyl alcohol
■ A single swab can be used
for many cleanings or until the
alcohol is gone
Description Qty. Cat. No.
Split-Tip Fiber Optic Swabs Bag of 20 45-360
■ For optimum connector
polishing results, we
recommend a three-step
procedure using 0.5µm,
3µm and 12µm 3 in. x 6 in.
aluminum oxide polishing
films
■ Lot-to-lot consistency in our
films means repeatable connector
finishes on ceramic, stainless steel,
plastic and composite ferrules
■ A single sheet will typically yield 10 to 20 connectors when using
the recommended 3-step procedure
Description Color Qty. Cat. No.
0.5µm, 3” x 6”, Aluminum Oxide Ivory 20 films/sleeve 45-337
3.0µm, 3” x 6”, Aluminum Oxide Lt. Yellow 20 films/sleeve 45-338
12µm, 3” x 6”, Aluminum Oxide Lt. Red 20 films/sleeve 45-339
Plastic Polishing
Fixture
■ Universal fitting accepts all ST ® , SC
and FC connectors with 2.5mm
ferrules
■ Economically priced
■ Grooved face for polishing efficiency
■ Precision tool used by manufacturers, contractors and in tool kits
Description Cat. No.
Plastic Polishing Fixture 45-342
Note: ST ® is a registered trademark of AT&T.
Stainless Steel Polishing Fixture for
Optical Fiber ST
® and
SC Type Connectors
Produces polished fiber optic ST ® and
SC type connectors for optimum
connector performance.
■ Precision-machined, stainless-steel
disk provides accurate polishing angle
for desired end face finish
■ Stainless-steel hardness maintains long life and resists
uneven wear
■ Stepped surface reduces drag and friction for easier polishing
Description Qty. Cat. No.
Polishing Fixture for Optical Fiber
1 45-341
SC/ST ® Type Connectors
Note: ST ® is a registered trademark of AT&T.
45-339
45-338
45-337
Stripmaster ® Ribbon Fiber
Jacket Stripper
Description Cat. No.
Stripmaster ® Wire Stripper Frame only L-5620
Blade-set for use with Corning Plenum and Riser Ribbon Fiber Cable LB-1152
Blade-set for use with Corning “Fanout” Ribbon Cable LB-1153
Note: Kevlar ® is a registered trademark of DuPont.
■
Removes jacket from Ribbon Fiber without
damage to the Kevlar
® strength member of
the Ribbon Fiber
Note: Frame and blade-set sold separately.
