Description Qty. Cat. No.
25 85-351
6-Position 4-Contact Flat Stranded 50 85-401
100 86-401
25 85-352
6-Position 6-Contact Flat Stranded 50 85-402
100 86-402
4-Position 4-Contact Flat Stranded (Handset) 100 86-398
25 85-353
8-Position 8-Contact Flat Stranded 50 85-403
100 86-403
25 85-344
6-Position 4-Contact Round Solid 50 85-394
100 86-394
6-Position 6-Contact Round Solid 100 86-395
8-Position 8-Contact CAT 6 Modular Plug 25 85-366
25 85-346
8-Position 8-Contact Round Solid 50 85-396
100 86-396
85-344
Modular Plugs
■
All plugs comply with FCC 86 guidelines and are UL Listed
■
Plugs are capable of supporting the latest EIA/TIA cable system
performance categories when installed in compliance with
appropriate EIA/TIA standards and methods
■
Plugs offered for round cable with solid conductors and
for flat cable and stranded conductors
■
Position and contact configurations cover popular styles
IDC connectors create fast splice
and tap connections on solid copper
wires. Designed for low voltage
telecommunication cables.
■ Moisture-resistant sealant protects
wires from corrosion
■ Use with solid copper single-conductor
wire
■ Kinetic Super™ Wire Stripper/Crimper
easily cuts and strips 22 to 24 AWG solid wire
Insulation Displacement
Connectors (IDC)
85-900 85-925
85-950
Description Qty. Cat. No.
UB-I, 2-Wire Tap Splice IDC 25 85-900
UR-I, 3-Wire Butt Splice IDC 25 85-925
UY-I, 2-Wire Butt Splice IDC 25 85-950
UR-I, 2-Wire Butt Splice IDC 100 86-925
UY-I, 2-Wire Butt Splice IDC 100 86-950
UB-I, 2-Wire Tap Splice IDC 1,000 87-900
UR-I, 3-Wire Butt Splice IDC 1,000 87-925
UY-I, 2-Wire Butt Splice IDC 1,000 87-950
IDC Combo Pack 25 85-960
Kinetic Super™ Wire Stripper/Crimper 1 45-719
CAT 6 Modular Plugs
Description Qty. Cat. No.
CAT 6 Modular Plugs 25 85-366
■ Supports CAT 6
■ Unique three-piece design provides
easy installation and optimal performance
■ Crimps with a standard RJ-45 crimp die
■ 50 micron gold contacts, 8-position, 8-contact
■ Suitable for solid or stranded conductors
Also available in these kits:
33-750 33-704 33-652
