Splitters
DataComm Equipment
1-800-435-0705 for Customer Service www.idealindustries.com G-17
Surge Suppression Cable Splitters
4-Way Digital Surge Suppression Cable Splitters withstand a one-time surge up to 6KV on cable line
Q Bandwidth: 5 MHz - 1 GHz
Q Impedance: 75 ohm
Q Over 130 dB of RFI Shielding
Q Low 8 db Insertion Loss
Description Cat. No.
2-Way Surge Suppression Splitter 85-135
4-Way Surge Suppression Splitter 85-137
Grounding Blocks
Q Solid zinc alloy, nickel plated and chromate finished
Q High Performance beryllium copper contact
Q Excellent electrical performance 0 - 3,000 MHz
Q Dual grounding holes can accept up to #6 wire
Q UL/CSA approved
Description Qty. Cat. No.
3 GHz Double Grounding Block 1/card 85-311
3 GHz Quad-Square Grounding Block 1/card 85-313
85-311 85-313
Satellite and Digital TV Splitters
Description Qty. Cat. No.
2-Way, 5MHz - 2.3GHz 1 85-332
3-Way, 5MHz - 2.3GHz 1 85-333
4-Way, 5HMz - 2.3GHz 1 85-334
85-332
85-333
85-334
Description Quantity Cat. No.
CATV Cable Splitter, 5-900 MHz, 2-Way Card of 1 85-032
CATV Cable Splitter, 5-900 MHz, 3-Way Card of 1 85-033
CATV Cable Splitter, 5-900 MHz, 4-Way Card of 1 85-034
High Performance Cable Splitter, Card of 1 85-132
5MHz-1GHz 2-Way Box of 10 86-132
High Performance Cable Splitter, Card of 1 85-133
5MHz-1GHz 3-Way Box of 10 86-133
High Performance Cable Splitter, Card of 1 85-134
5MHz-1GHz 4-Way Box of 10 86-134
Splitters
85-132 85-134
Description Cat. No.
Digital Cable Splitter, 8-Way 85-138
Digital Cable Splitter
Q Nickel-plated housing
Q High-performance impedance-balanced
Printed Circuit Board design
Q Bandwidth: 5MHz - 1 GHz Impedance: 75 Ohm; over 120 dB of
RFI shielding; Splits signals up to 8 outlets
Diplexer, 2.3 GHz
Q Combine or split cable/antenna signals
with satellite signals
Q High quality PCB design
Q Nickel-plated die-cast zinc housing
Q Grounding hole for up to 6 AWG wire
Q PCB Printed Circuit Board Design
Q Nickel Plated Housing
Q Splits signals up to 4 outlets
85-133
Description Cat. No.
Diplexer, 2.3 GHz, SATV/TV Combiner Splitter - 2 Amp 85-323
Q Designed for easy mounting over cable
Q All ports are F female connectors, 75Ω
Q Two grounding screws eliminate the need for grounding block
Q Single port power pass
Terminators (85-038) needed for all unused
ports for optimal performance
