Text mode
Original mode

AFP SUMMARY

IPS SOLUTIONS GUIDE

2-15

TCP/IP connection: Token Ring

For the Token Ring TCP/IP connection, you must have a Token Ring
card installed inside the RS/400. A router directs the jobs being run
on the Token Ring to the appropriate device.

PS/2 connections

You can connect your PS/2 system to the DocuPrint IPS printers
using any of the remote connection methods described in this
section.

Stand-alone PSF/2

The simplest way to connect your DocuPrint IPS printers to a PS/2 is
through a stand-alone system. If you choose this connection, you
may need to offload your resources and data streams from the host
and upload them onto the PS/2 system. Then, you can print AFP
documents to the DocuPrint IPS printer through PSF/2 via a channel
card in the PS/2.
