Specifications
A–2
Electrical Performance (Inverter)
Physical (Inverter)
Dimensions (Remote On/Off Switch)
Specifications are subject to change without notice.
Output power at 68º F (20º C) ambient
and 12 Vdc input:
• Continuous power
• Surge power
1000 W
2000 W
Output voltage 115 Vac RMS ±5%
Output waveform Modified sine wave (quasi-
square wave)
Output frequency 60 Hz ±0.01%
Input voltage 10–15 Vdc
Low battery alarm Audible, 10.7 V
Low battery cutout 10.0 V
Efficiency Approximately 85–90%
No load current draw <0.3 A
Length 10 inches (26 cm)
Width 9 inches (24 cm)
Height 3 inches (8 cm)
Weight 5.2 lb (2.4 kg)
Length 4.25 inches (10.80 cm)
Width 2.5 inches (6.35 cm)
Depth 0.7 inches (18 mm)
Cable Length 20 ft (6 m)
