Remote Communication & Monitoring
4-18 TM-DIOP-01XN-01
Table 4-6 Monitor Page of Web Interface
Object Description
Output Voltage Last measured output voltage (Vrms)
Output Current Last measured output current (Arms)
Percent Load Last measured percent load (%). Indicates percentage of
load being drawn from the inverter with respect to
maximum load capability
Startup Status of startup sequence
Fault Status List of current faults of the inverter (see Table 4-7 on
page 4–19)
Faults Since Power
On List of faults that have occurred since power up (see
Table 4-7)
On LED Indicates state of the inverter:
Green – Inverter is operating normally
Yellow – Inverter is running startup sequence, or in
standby mode
Off – Inverter’s output is disabled because a fault has
occurred.
Fault LED Indicates fault condition:
Red – Inverter has a fault condition
Off – Inverter is operating normally
Refresh Data Link Updates all the data on the page. Select this every time
the “Monitor Page Refresh Rate” parameter has been
changed.
Close Window
Link Closes the page
