Rack Mount Frame Assembly and Installation
2-14 TM-DIOP-01XN-01
CAN/SYNC Wiring
Due to high bus speed, use shielded twisted pairs of 22-24 AWG for
improved noise immunity. Before making any connections, ensure power
to the rack has been disconnected. Carefully route the wires away from
high power load cables to minimize noise effects on signal integrity.
Table 2-2 CAN/SYNC Pin-out
Terminals Function
1 Return/GND
2 CAN-LO
3 CAN-HI
4 Return/GND
5 SYCN-OUT 240 degrees
6 SYCN-OUT 120 degrees
7 SYCN-OUT 0 degrees
