Figure 3-1, Installing an inverter into a rack –3, Figure 3-2 – Xantrex Technology XDI2048 User Manual
Page 45: Inverter front panel –3, Fer to figure 3-1, Figure 3-2) i
Installation into Rack Mount Frame
TM-DIOP-01XN-01
3-3
1. Captive Screw
2. Handle
3. Power Switch
4. Air Intake Vents
5. “Fault” and “ON” LED’s
Uninstalling
To uninstall the inverter module, release the captive screws and slide the
module out.
Figure 3-1 Installing an Inverter into a Rack
Figure 3-2 Inverter Front Panel
5
4
2
1
3
5
4
3
2
1
