Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA
CONDENSING UNIT MODEL NO YHJD 60S41S1
EVAPORATOR COIL MODEL NO FC/MC62
AIR TEMP.
ENTERING
OUTDOOR UNIT
AIR TEMP.
ENTERING
INDOOR COIL
ID CFM
1600 1800 2000
MBTUH KW C.O.P. MBTUH KW C.O.P. MBTUH KW C.O.P.
60
60 65.7 4.7 4.1 66.7 4.6 4.2 67.6 4.6 4.3
70 64.7 5.1 3.7 65.4 5.0 3.8 66.1 4.9 3.9
80 63.8 5.5 3.4 64.1 5.4 3.5 64.5 5.3 3.6
47
60 56.9 4.4 3.8 57.4 4.4 3.9 58.0 4.3 4.0
70 55.8 4.8 3.4 56.3 4.8 3.5 56.8 4.7 3.5
80 54.7 5.2 3.1 55.2 5.2 3.1 55.6 5.1 3.2
40
60 51.9 4.3 3.5 51.7 4.3 3.5 51.4 4.3 3.5
70 50.6 4.8 3.1 51.1 4.7 3.2 51.7 4.7 3.2
80 49.3 5.2 2.8 50.6 5.1 2.9 51.9 5.0 3.0
30
60 44.1 5.0 2.6 43.6 5.0 2.5 43.1 5.0 2.5
70 45.3 4.6 2.9 44.8 4.6 2.9 44.4 4.6 2.8
80 46.5 4.2 3.2 46.1 4.2 3.2 45.6 4.1 3.2
17
60 36.6 5.0 2.2 36.8 4.9 2.2 36.9 4.9 2.2
70 36.0 4.5 2.4 36.5 4.5 2.4 37.1 4.4 2.4
80 35.3 4.0 2.6 36.3 4.0 2.6 37.3 4.0 2.7
10
60 27.3 4.7 1.7 27.7 4.6 1.7 28.1 4.6 1.8
70 30.4 4.4 2.0 31.2 4.3 2.1 32.0 4.3 2.2
80 33.4 4.0 2.4 34.7 4.0 2.5 35.9 4.0 2.7
NOTE: ALL CAPACITIES ARE NET (KBTUH) WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handlers Coils MBH KW COP
AHX60 – 1.00 1.02 0.99
F6FP060 – 0.99 1.01 0.98
MA20D MC62D 1.00 1.00 1.00
MV20D MC62D 0.99 0.99 1.00
Furnaces Coils MBH KW COP
T*(8,L)X*C20 FC/MC62D 0.98 1.02 0.96
T*9X*D20 FC/MC62D 0.98 0.97 1.01
( Y *9C/T*9V)*D20 FC/MC/PC60D 0.98 0.97 1.02
Y *(8,L)C*C20 FC/MC62D 0.98 1.01 0.98
( Y *9C/T*9V)*C20 FC/MC62D 0.99 0.99 1.01
