Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
CONDENSING UNIT MODEL NO.
YHJD
24S41S1
INDOOR COIL MODEL NO.
AHP30
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM
600
800
1000
ID DB (°F)
80
80
75
80
80
80
80
75
80
80
80
80
75
80
80
ID WB (°F)
57
62
62
67
72
57
62
62
67
72
57
62
62
67
72
65
T.C.
22.9 26.4 25.6 29.2 31.5 25.8 28.0 27.2 30.7 33.2 28.8 29.6 28.8 32.2 35.0
S.C.
21.8 20.2 17.3 17.7 15.1 24.6 23.7 19.4 19.6 16.2 27.4 27.2 21.5 21.6 17.4
KW
1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5
75
T.C.
21.9 24.6 24.1 27.3 29.5 24.5 26.0 25.5 28.6 31.1 27.0 27.4 26.9 30.0 32.6
S.C.
20.8 19.4 16.5 16.8 14.3 23.3 22.4 18.6 18.8 15.4 25.7 25.4 20.7 20.8 16.5
KW
1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6
85
T.C.
20.9 22.9 22.6 25.3 27.6 23.1 24.1 23.7 26.5 28.9 25.3 25.3 24.9 27.8 30.3
S.C.
19.9 18.6 15.8 16.0 13.4 22.0 21.2 17.9 18.0 14.5 24.1 23.7 20.0 20.0 15.6
KW
1.7 1.7 1.7 1.7 1.8 1.7 1.7 1.7 1.8 1.8 1.8 1.7 1.7 1.8 1.8
95
T.C.
19.8 21.1 21.0 23.4 25.6 21.7 22.1 22.0 24.5 26.8 23.5 23.1 23.0 25.6 27.9
S.C.
18.9 17.8 15.0 15.1 12.6 20.6 19.9 17.1 17.2 13.7 22.4 22.0 19.2 19.2 14.8
KW
1.8 1.8 1.8 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.9
105
T.C.
18.4 19.1 19.2 21.5 23.5 20.1 20.3 20.0 22.3 24.5 21.8 21.5 20.8 23.2 25.5
S.C.
17.6 16.7 14.3 14.4 11.7 19.2 18.6 16.2 16.4 12.8 20.8 20.5 18.1 18.4 13.9
KW
1.9 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.1
115
T.C.
17.1 17.3 17.4 19.6 21.5 18.6 18.6 18.0 20.2 22.3 20.1 20.0 18.7 20.9 23.1
S.C.
16.3 15.7 13.5 13.6 10.8 17.7 17.4 15.2 15.6 12.0 19.2 19.1 16.9 17.6 13.1
KW
2.1 2.1 2.1 2.1 2.2 2.1 2.1 2.1 2.1 2.2 2.2 2.2 2.1 2.2 2.2
125
T.C.
15.8 15.4 15.6 17.7 19.5 17.1 17.0 16.1 18.2 20.1 18.5 18.5 16.6 18.6 20.7
S.C.
15.0 14.7 12.7 12.9 10.0 16.3 16.1 14.3 14.9 11.1 17.6 17.6 15.8 16.9 12.2
KW
2.2 2.2 2.2 2.2 2.3 2.2 2.2 2.2 2.3 2.3 2.3 2.3 2.2 2.3 2.3
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handlers
Coils
T.C.
S.C.
KW
–
FC/MC/PC24 0.98
0.98
1.00
–
FC/MC/PC30 0.98
0.98
1.00
–
FC/MC/PC32 1.00
1.00
1.00
–
FC/MC/PC35 1.00
1.00
1.00
–
HC30 0.98
0.99
1.00
–
HC36 1.00
1.00
1.00
–
HD36 0.98
0.94
1.00
AHP30 –
0.99
0.98
1.00
AHX30
–
1.02
1.06
0.93
AHX36
–
1.04
1.08
0.91
AV*24 –
0.99
0.98
1.00
AV*36
–
1.02
1.01
0.91
F4FP030 –
0.99
0.97
1.00
F6FP030
–
1.03
1.06
0.95
F6FP036
–
1.02
1.07
0.94
MA08B FC/MC/PC24B
0.98
0.98
1.00
MV12B FC/MC/PC24B
1.01
1.00
1.00
MA08B FC/MC/PC30B
0.98
0.98
1.00
MV12B FC/MC/PC30B
1.01
1.01
1.00
MA08B FC/MC/PC35B
1.00
1.00
1.00
MV12B FC/MC/PC35B
1.02
1.02
1.00
MV16C FC/MC/PC35C
1.02
1.02
1.00
Furnaces
Coils
T.C.
S.C.
KW
T*9X*B12
FC/MC/PC35B
1.02
1.04
0.91
T*(8,L)X*A12
FC/MC/PC37A
1.05
1.10
0.91
T*(8,L)X*B12
FC/MC/PC43B
1.06
1.12
0.91
T*9X*B12
FC/MC/PC43B
1.04
1.07
0.91
T*(8,L)X*B12
FC/MC/PC35B
1.04
1.09
0.91
T*9X*C16
FC/MC/PC35C
1.00
1.00
0.90
T*(8,L)X*A12
FC/MC/PC32A
1.02
1.05
0.91
Y
*(8,L)C*A12
FC/MC/PC32A
1.01 1.01 0.94
Y
*(8,L)C*B12
FC/MC/PC35B
1.02 1.01 0.93
(
Y
*9C/T*9V)*B12 FC/MC/PC35B
1.03 1.03 0.94
Y
*(8,L)C*A12
FC/MC/PC37A
1.03 1.04 0.95
Y
*(8,L)C*B12
FC/MC/PC43B
1.03 1.02 0.93
(
Y
*9C/T*9V)*B12 FC/MC/PC43B
1.04 1.04 0.94
Y
*(8,L)C*B12
HC36
1.02 1.00 0.93
(
Y
*9C/T*9V)*B12 HC36
1.03 1.03 0.94
Y
*(8,L)C*A12
HD36
1.00 0.99 0.93
Y
*(8,L)C*B12
HD36
1.00 0.96 0.93
Y
*(8,L)C*C16
HD36
1.02 1.02 0.92
Y
*(8,L)C*C20
HD36
1.00 0.96 0.91
(
Y
*9C/T*9V)*B12 HD36
1.00 0.99 0.93
(
Y
*9C/T*9V)*C16 HD36
1.00 1.00 0.92
(
Y
*9C/T*9V)*C20 HD36
1.00 0.96 0.92
