397855-YTG-G-0509
28 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA
CONDENSING UNIT MODEL NO YHJD 18S41S1
EVAPORATOR COIL MODEL NO AHP18
AIR TEMP.
ENTERING
OUTDOOR UNIT
AIR TEMP.
ENTERING
INDOOR COIL
ID CFM
450 600 750
MBTUH KW C.O.P. MBTUH KW C.O.P. MBTUH KW C.O.P.
60
60 19.7 1.6 3.7 21.0 1.6 3.9 22.3 1.6 4.2
70 18.3 1.6 3.3 19.6 1.6 3.5 20.9 1.6 3.8
80 16.8 1.7 2.9 18.1 1.7 3.2 19.5 1.7 3.4
47
60 16.4 1.5 3.3 17.6 1.5 3.5 18.8 1.5 3.7
70 15.2 1.5 3.0 16.4 1.5 3.2 17.6 1.5 3.3
80 14.0 1.5 2.7 15.2 1.6 2.8 16.4 1.6 3.0
40
60 14.9 1.4 3.1 16.2 1.4 3.3 17.5 1.5 3.5
70 12.4 1.4 2.5 14.3 1.5 2.9 16.3 1.5 3.2
80 9.9 1.5 2.0 12.5 1.5 2.4 15.0 1.6 2.8
30
60 10.3 1.3 2.2 11.5 1.4 2.4 12.7 1.5 2.5
70 11.5 1.3 2.5 12.7 1.4 2.7 14.0 1.4 2.9
80 12.6 1.3 2.8 13.9 1.4 3.0 15.2 1.4 3.2
17
60 7.6 1.2 1.9 7.8 1.3 1.8 7.9 1.4 1.7
70 8.2 1.2 2.0 8.5 1.3 2.0 8.8 1.3 2.0
80 8.8 1.2 2.2 9.2 1.2 2.2 9.7 1.3 2.2
10
60 6.1 1.1 1.6 6.7 1.2 1.6 7.3 1.3 1.7
70 6.2 1.1 1.6 7.1 1.2 1.7 8.0 1.3 1.8
80 6.2 1.1 1.6 7.4 1.2 1.8 8.6 1.3 2.0
NOTE: ALL CAPACITIES ARE NET (KBTUH) WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handlers Coils MBH KW COP
– FC/MC/PC18 1.00 1.00 1.00
– FC/MC/PC24 1.03 1.04 0.99
– HC18 1.00 1.00 1.00
– HC30 1.02 1.02 0.99
– HD24 0.97 0.96 1.02
AHP18 – 1.02 1.02 1.00
AV24 – 0.98 0.99 1.00
F4FP024 – 1.01 1.01 1.00
MV12B FC/MC/PC18B 0.98 0.98 1.00
MA08B FC/MC/PC18B 1.00 1.00 1.00
MA08B FC/MC/PC24B 1.03 1.04 0.99
MV12B FC/MC/PC24B 1.00 1.02 0.99
Furnaces Coils MBH KW COP
Y *(8,L)C*A12 FC/MC/PC18A 0.98 1.07 0.92
Y *(8,L)C*B12 FC/MC/PC18B 0.97 1.06 0.92
( Y *9C/T*9V)*B12 FC/MC/PC18B 0.98 1.07 0.92
Y *(8,L)C*A12 FC/MC/PC24A 1.01 1.10 0.92
Y *(8,L)C*B12 FC/MC/PC24B 0.99 1.10 0.90
( Y *9C/T*9V)*B12 FC/MC/PC24B 1.01 1.11 0.91
Y *(8,L)C*A12 FC/MC/PC30A 1.01 1.10 0.92
Y *(8,L)C*B12 FC/MC/PC30B 0.99 1.10 0.90
( Y *9C/T*9V)*B12 FC/MC/PC30B 1.01 1.11 0.91
Y *(8,L)C*A12 HC18 0.98 1.07 0.92
Y *(8,L)C*A12 HC30 0.99 1.07 0.93
Y *(8,L)C*A12 HD24 0.98 1.06 0.93
Y *(8,L)C*B12 HD24 0.96 1.04 0.92
( Y *9C/T*9V)*B12 HD24 0.98 1.07 0.92
Y *(8,L)C*A12 UC18A 0.99 1.08 0.92
Y *(8,L)C*B12 UC18B 0.98 1.07 0.92
( Y *9C/T*9V)*B12 UC18B 0.99 1.08 0.91
Y *(8,L)C*A12 UC24A 1.02 1.11 0.91
Y *(8,L)C*B12 UC24B 0.99 1.10 0.90
( Y *9C/T*9V)*B12 UC24B 1.01 1.12 0.91
Y *(8,L)C*A12 UC30A 1.01 1.11 0.91
Y *(8,L)C*B12 UC30B 0.99 1.10 0.90
( Y *9C/T*9V)*B12 UC30B 1.01 1.12 0.91
