Johnson Controls Unitary Products 29
Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA
CONDENSING UNIT MODEL NO YHJD 24S41S1
EVAPORATOR COIL MODEL NO AHP24
AIR TEMP.
ENTERING
OUTDOOR UNIT
AIR TEMP.
ENTERING
INDOOR COIL
ID CFM
600 800 1000
MBTUH KW C.O.P. MBTUH KW C.O.P. MBTUH KW C.O.P.
60
60 28.4 2.1 4.0 30.1 2.0 4.3 31.8 2.0 4.6
70 26.7 2.2 3.6 28.4 2.2 3.9 30.1 2.1 4.1
80 25.1 2.3 3.2 26.8 2.3 3.5 28.5 2.2 3.7
47
60 23.4 1.9 3.5 24.5 1.9 3.7 25.7 1.9 3.9
70 22.0 2.0 3.2 22.2 2.0 3.3 22.4 2.0 3.3
80 20.6 2.1 2.9 19.9 2.0 2.9 19.1 2.0 2.8
40
60 20.7 1.9 3.2 21.9 1.9 3.4 23.1 1.9 3.5
70 19.3 1.9 2.9 20.4 2.0 3.1 21.6 2.0 3.2
80 17.9 2.0 2.7 19.0 2.0 2.8 20.0 2.1 2.9
30
60 17.2 1.7 2.9 18.1 1.8 3.0 19.0 1.8 3.0
70 15.8 1.8 2.6 16.7 1.8 2.7 17.6 1.9 2.7
80 14.3 1.8 2.3 15.2 1.9 2.4 16.2 1.9 2.5
17
60 7.9 1.6 1.5 11.2 1.6 2.0 14.4 1.7 2.5
70 9.0 1.6 1.7 11.0 1.7 1.9 13.0 1.7 2.2
80 10.0 1.6 1.8 10.9 1.7 1.9 11.7 1.7 2.0
10
60 10.5 1.5 2.1 11.2 1.6 2.1 11.9 1.6 2.1
70 9.3 1.5 1.8 9.9 1.6 1.9 10.6 1.6 1.9
80 8.0 1.5 1.6 8.6 1.6 1.6 9.3 1.6 1.7
NOTE: ALL CAPACITIES ARE NET (KBTUH) WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handlers Coils MBH KW COP
– FC/MC/PC24 1.00 1.00 1.00
– FC/MC/PC30 1.00 1.00 1.00
– FC/MC/PC32 1.00 1.00 1.00
– FC/MC/PC35 1.00 1.00 1.00
– HC30 0.99 0.99 1.01
– HC36 1.00 1.00 1.00
– HD36 1.35 1.41 0.96
AHP30 – 1.01 1.01 1.00
AHX30 – 0.99 1.07 0.92
AHX36 – 0.99 1.12 0.89
AV24 – 0.96 0.95 1.01
AV*36 – 0.97 1.08 0.90
F4FP030 – 0.99 0.99 1.01
F6FP030 – 0.99 1.05 0.94
F6FP036 – 0.99 1.07 0.92
MA08B FC/MC/PC24B 1.00 1.00 1.00
MV12B FC/MC/PC24B 0.98 0.98 1.00
MA08B FC/MC/PC30B 1.00 1.00 1.00
MV12B FC/MC/PC30B 0.98 0.98 1.00
MA08B FC/MC/PC35B 1.00 1.00 1.00
MV12B FC/MC/PC35B 0.98 0.98 1.00
MV16C FC/MC/PC35C 0.98 0.98 1.00
Furnaces Coils MBH KW COP
T*9X*B12 FC/MC/PC35B 0.98 1.08 0.91
T*(8,L)X*A12 FC/MC/PC37A 1.00 1.12 0.89
T*(8,L)X*B12 FC/MC/PC43B 1.00 1.13 0.89
T*9X*B12 FC/MC/PC43B 0.99 1.11 0.90
T*(8,L)X*B12 FC/MC/PC35B 0.99 1.10 0.90
T*9X*C16 FC/MC/PC35C 0.96 1.06 0.90
T*(8,L)X*A12 FC/MC/PC32A 0.98 1.08 0.90
Y *(8,L)C*A12 FC/MC/PC32A 0.98 1.04 0.95
Y *(8,L)C*B12 FC/MC/PC35B 0.98 1.05 0.93
( Y *9C/T*9V)*B12 FC/MC/PC35B 0.99 1.05 0.94
Y *(8,L)C*A12 FC/MC/PC37A 1.00 1.07 0.93
Y *(8,L)C*B12 FC/MC/PC43B 0.98 1.07 0.92
( Y *9C/T*9V)*B12 FC/MC/PC43B 0.99 1.07 0.93
Y *(8,L)C*B12 HC36 0.97 1.05 0.93
( Y *9C/T*9V)*B12 HC36 0.99 1.05 0.94
Y *(8,L)C*A12 HD36 0.90 0.90 1.00
Y *(8,L)C*B12 HD36 0.89 0.89 1.00
Y *(8,L)C*C16 HD36 0.91 0.93 0.98
Y *(8,L)C*C20 HD36 0.88 0.89 0.98
( Y *9C/T*9V)*B12 HD36 0.90 0.90 1.00
( Y *9C/T*9V)*C16 HD36 0.90 0.91 0.99
( Y *9C/T*9V)*C20 HD36 0.88 0.89 0.99
